CNC High Speed Door Leaf Four Edge Cutting Machine

CNC door four edge saw MJK6424C1Function:The machine is special for door four edges precise sizing to requested size.Feature:1. Design of main & scoring saw ensures cutting without edge broken.2. With smashing cutter to smash waste strip, longitudinal saws group can tilt to meet demand of cutting bevel edge at 0-5 degree.3. Automatic push the door to machine center in lengthwise direction to evenly cut both side waste material.4. Automatic adjustable vacuum sucking worktable, to satisfy demand of door leaf's size frequency change.5. Through-feed automatic feed-in & feed-out, feed-out direction could be forward or backward, to satisfy demand of single machine use and compose a line.Saw groupConnect with other machines to be full automatic lineCustomer workshopTechnical specification:Workpiece length: 1800-2400mmWorkpiece width: 500-1100mm Workpiece thickness: 30-60mmMain saw motor: 3*7.5kwScoring saw motor: 3*1.5kwMax moving speed of sawblade: 40m/minMax cutting & smashing waste strip width at each edge: 10mmOverall dimensions: 5600*3100*2100mmWeight: 5000kgVoltage: 380V, 50HZ, 3Phase  CNC door four edge saw MJK6424HFunction:The machine is special for door four edges precise sizing to requested size.Feature:1. Design of main & scoring saw ensures cutting without edge broken.2. Four saw group with smash knife to remove excess material.3. Automatic push the door to machine center in lengthwise direction to evenly cut both side waste material.4. Length & width two-way automatic adjustable vacuum sucking worktable, to satisfy demand of door leaf's size frequency change.5. Automatic feed-in & feed-out, feed-out direction could be forward or backward, to satisfy demand of single machine use and compose a line.6. Bar code scanning, automatic lubrication.Machine inside:Customer workshopMain difference between MJK6424C1 and MJK6424H:ItemMJK6424C1MJK6424HEfficiency75 seconds per door50 seconds per door Feed in directionLengthwaysTransverse(need additional feed in table and feed out table)Sawblade quantityThree group(each group including one main saw and one scoring saw)Four group(each group including one main saw and one scoring saw)Process stepAs per below drawingAs per below drawingConnected in automatic lineAvailableAvailableOptional with barcode scan functionAvailableAvailable/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
