Automatic CNC Glass Cutting Machine Flat Glass Cutter

Product Description1. Machine Introduction of Automatic CNC Glass Cutting Machine Flat Glass CutterThe CNC Glass Cutting Machine Automatic Glass Cutting Machine is always working in completely CNC Glass Cut Line. It includes the parts following:   NODESCRIPTIONMODELQTYNOTES1Automatic glass loading table (Double turning double station)QSP-52331Max FLAT Glass Process Size:5200*3300mm2Automatic glass cutting machine (Dual drive)CNC-52331Max FLAT Glass Process Size:5200*3300mm3Air levitation glass breaking tableBQZ-52331Max FLAT Glass Process Size:5200*3300mm4Supplied AccessoriesSucker 2 Debugging tools 1 Round knife holder 8 Round tool holder assembly 2 PU Roller 2   Detailed Photos 2. Machine Parts Details for Automatic CNC Glass Cutting Machine Flat Glass CutterAAutomatic glass loading table(Double turning double station)The automatic glass loading table is mainly composed of frame system, turning system, suction cup lifting system, X-axis traveling system (it is not available for single station), Y-axis traveling system, conveying system, vacuum and pneumatic control system, and electrical control system eight big parts.BAutomatic glass cutting machine(Dual drive)The automatic glass cutting machine is a key part of this set of complete machine line, which is mainly composed of seven parts: chassis system, beam system, worktable system, cutter head system, conveying system, photoelectric scanning positioning system, and electrical control system.CAir levitation glass breaking tableThe Air levitation glass breaking table is mainly composed of five parts: frame system, air flotation mechanism, sheet breaking mechanism, fan device, and air-electric control systemDSupplied AccessoriesSucker, Debugging tools, Round knife holder, Round tool holder assembly, PU Roller  3. Machine Device Configuration OF Automatic CNC Glass Cutting Machine Flat Glass Cutter   Mechanical Configuration Electrical ComponentsPlateUse high-strength platesControllerGalil or GUGAO GearsTaiwan brandservo motorJapanese brandConveyor belt / WheelsJoint ventureRelayschneiderian FranceKnife wheelBohle  GermanyTerminalWEIDMULLER,  GermanyKnife boxNon-skin patent knife boxProportional solenoid valveSMC,  JapanKnife holderAnti-dropping patent round (column) tool holderMain cableTaiwan Xinguang flexible cable,UL certificationKnife box back plateAviation alloy aluminum integral castinglaser sensorPANSONIC,  JapanProduct Parameters 4. Technical Parameter of Automatic CNC Glass Cutting Machine Flat Glass Cutter  Machine Size6350mm*4200mmMachine Weight4TMaximum size of flat glass that can be cut5200mm*3300mm Flat glassHeight of worktable900mm±20mmCutting thickness3~19mm Flat glassFuel supply methodPneumatic automatic oil fillingCutting speed0~180m/min( Adjustable)Install the power supply380V/50HZ(Three-phase four-wire)Straight line parallelism≤±0.20mm/mMachine power7.5KWDiagonal accuracy≤±0.25mm/mThe above accuracy is subject to the accuracy of the cutting line before breaking the filmCompressed air0.6MPaProvided by the userBelt transmission speed30m/min( Adjustable)Cutting knife holder360°The cutter head can rotate 360°Can accurately cut any straight line and various special-shaped glass  Our Advantages5. Performance on Automatic CNC Glass Cutting Machine Flat Glass Cutter  5.1. Cutting knife holderThe Japanese SMC proportional solenoid valve is used to automatically adjust the pressure according to the thickness of the glass. The knife head rotates 360 degrees, and the lower knife buffers the cutting. The knife box adopts our company's patented product.5.2. CountertopIt is made of high-strength boards and wrapped with wooden lines.5.3 FeltIndustrial felt has good flatness and is anti-static and avoids adhesion of glass chips.5.4 Positioning systemAutomatic edge finding and positioning system, no need to be edged, greatly improving the glass cutting rate.5.5 cutting oil supply methodThe oil circuit is equipped with an air filter device to ensure that the cutting oil is used cleanly. The oil is automatically injected during cutting and synchronized with the cutting.5.6 Conveying deviceBelt conveyor (no air float).5.7 Linear guide for guide railHigh cutting accuracy and low noise.5.8 Function expansionThe head part can expand the function of automatic labeling or film removal. This mechanism is an optional function, not a host configuration, and needs to be optional.5.9 Motion Controller (American Galil or GUGAO)(1) Fast running speed, stable running, high control precision, modularized controller structure;(2) Pipeline cutting mode, photoelectric positioning cutting mode, and direct cutting mode can be set freely through options. Switch between automatic cutting mode and no-load running mode at any time during processing;(3) Complete glass pressure library storage. After inputting and saving the cutting pressure of each specification and thickness at one time, it can be directly quoted;(4) Real-time tracking and display of processing path, real-time re
