Cabinet Wooden Door Woodworking CNC Router

Basic Info.Model NO.YN-1325CertificationGS, CEUsageWoodworking, Metal, Plastic, Stone, AdvertisingCurrentACPowerHigh PowerControlCNCDrive TypeStepper DriveColorCustomedMain MarketsEurope, USA, Middle East, Southeast AsiaDelivery Detail3 Days DeliveryApplicationNonmetal and Thin Metal MaterialsDriver MotorsStepper Motor and DriverWorking MaterialsNonmetal and Thin Metal MaterialsControlsDSP a 11(Digital Signal Processor)TrademarkYNTransport PackagePlywood CaseSpecification1300*2500mmOriginShandong, ChinaHS Code8465990000Product Description        CE FDA Certificate DSP Control Wood CNC Router Machine    The CNC router is controlled by a computer. Coordinates are uploaded into the machine controller from a separate CAD program. CNC router owners often have two software applications-one program to make designs (CAD) and another to translate those designs into a 'G-Code' program of instructions for the machine (CAM). As with CNC milling machines, CNC routers can be controlled directly by manual programming, and CAD/CAM opens up wider possibilities for contouring, speeding up the programming process and in some cases creating programs whose manual programming would be, if not truly impossible, certainly commercially impractical. TECHNICIAL PAREMETERModelYN-1325WYN-1224WYN-1212WYN-1530WYN-2030WX-Y-Z axis working area (x-y-z)1300*2,500*200MM1200*2400*200MM1200*1200*200MM1500*3000*200MM2000*3000*200MMMachine Size2,150x3,150mmResolution0.0025mmZ axis height200mm, (300mm, 400mm optional)X.Y movementRack and pinionZ movementBall screw driver/GermanyGuideLinear 20 square/Taiwan Max. speed35,000mm/minMax. cutting speed25,000mm/minSpindle4.5KW (water cooling)/ China Qiancheng brand 4.5kwSpindle speed24000rpmDriver motorsStepperInverter power7.5KW /Sunfar Rotary axis(Optional)Working length 1500mm, diameter 100mmWorking voltageAC380V, 50/60HZ 3 phaseCommand codeG code GComputer interfaceUSB 2.2CollectER25-12.7mm,6MM, 3.175MMSoftwareRouter software/FranceControlsDSP A 11(Digital signal Processor)Packing dimensions2260x3250x1960mm, 1350KGSEquipments included1). Oil lubrication system2). Auto adjusting device3). 6 zone vacuum system with 5.5KW air cooled vacuum pump4). Double bags dust collector 3KWWarranty24 month for whole machine Delivery time7 daysCertificateCE  PRODUCT DESCRIPTION 1. CNC router with 4 axis, is specially for 4D work,the A axis can rotate 100 degree ; 2.With this machine, you can make different surface carving, arc-surface milling,bending surface machining for 4D jobs,like special shaped arts, bended doors or cabinets; 3.It can work on foam ,MDF,Acrylic,wood,and soft metal etc.FEATURES1. Adopt constant power 1.5kw water cooling spindle     ------- high speed, low noise and long life 2. Taiwan HIWIN square linear guide     ------- Top brand in china.  3. Popular NC studio control  and DSP control for optiona     --------It is very easy for every buyer and beginner. 4. Cast iron structure   --------never deformation 5. Mist water cooling sprayer and flume will cool the cutter   --------which is necessary when you cut or engrave on Aluminum,copper or other soft metal. APPLICATIONS1)advertising field                        2)seal field                                  3)packing field 4)pane making field                     5)decorating field                        6)art and craft field 7)architecture model field            8)souvenir field, badge field 9)electric circuitry field and carpentry field 10)it is used to engrave on Acrylic sheet, abs double color sheet, PVC foam sheet, wooden sheet, scagliola, PCB, granite, stone, steel and soft metal etc.FAQ1- How is your delivery  timeUsually it takes 8 days after your deposit,for stardard model we have in stock.if you need urgent,can arrange delivery quickly.2- What about after-sale service?We have detail English manual can guide you to run machine,if any doubt,our enginner will use Teamview tocontrol your software on your computer,meanwhile chat with you on skype.3- I want to see your machine,where is your factory?Our factory is located in Weifang City,Shandong Province. you can take flight to Weifang Airport.we can pick you up there.
