WPC PVC Door Board Making Machine- (engraving, sanding, laminating, painting)

WPC PVC door board making machine-(engraving, sanding, laminating, painting)SJSZseries PVC wood plastic door machinery mainly use PVC+wood powder to extrude wood-plastic door panels.Proper double screw extruder and single screw extruder,specially used for wood plastic products,can be choosen in accordance with the panel section,application,product specific gravity.Also the corresponding auxiliary machines such as vacuum shaping platform,hauling machine,saw machine,material reversing platform,etc.are equipped.Products of diversified specification can be produced with different dies.Component of WPC PVC door board making machine ItemNameModelQty.Remarks1.1Twin screw extruderSJSZ80/1561 unitEquipped with automatic spring feeding machine1.2Electrical control system 1setABB frequency convertorSIMENS contactorOMRON temperature controller.1.3Mold and vacuum calibrating machineSZD-60001unit 1.4haul offSLQ-6501unit 1.5Traverse cutting unitSQG-7001 unit 1.6ConveyorSXS-40001unit Instruction of WPC PVC door board making machineDescriptionParameterFeed materialPVC+ assistant materials(also can add wood powder)Product size(width600-900mm,thickness30-50mm)Production line speed0.8-1m/minMax. output350-500kg/hOutline size23×2.5×3 L×W×H(m),unsaturatedWeight16TTotal power255kwActual energy consumption power210kwConsumed air0.4m3/minAtmospheric pressure0.6mpaWater cycle0.3m3/minPowerAC380V±10%,50HZWaterIndustrial water, no impurity, with filtration treatment, pressure: 0.4Mpa temperature: 14-25°CWork environment temperature0-40°CProduction Flow of WPC PVC door board making machineCraft procedureHost machine extrusion→Vacuum calibrating→Haul off→Cutting→collecting→Convey→twin color stamping→drying→primer coating→levelling→painting→levelling→solidify forming→Convey→Checking up→Packing→FinishingOur ServicePre-Sales Service* Inquiry and consulting support. * Sample testing support by Bureau Veritas. * View our Factory.After-Sales Service* Training how to instal the machine, training how to use the machine. * Engineers available to service machinery overseas.Factory Show:   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
