CNC Metal Milling Carving Engraving Machine

Zhenyue CNC Metal Milling Carving Engraving MachineMain Features of SKDY Power Supply Series: Programmable 10-section fixed-depth and machining conditions, combined memory of 100-group machining depth conditions.Servo has two-velocity chip-removing function, It reinforces the stable machining.It applies constant current source EDM machining with little electrode loss and fine power-saving.It has division function. It can display set value of machining depth, the deepest value. current value at the same time.Reversible servo machining function.It matches with oil temperature protection, flame detector. It enhances the machining safety.  HNE250PARANETERUnit Machinery Specification  Work Table Sizemm280*450Work Tank Size(inner)mm730*480*310Axis Travel(X*Y*Z)mm150*250*200Max.Electrodr Weightkg25Max.Workpiece Weightkg250Electrode Platen To Work Tablemm370-570Tank CapacityL375Machine Weightkg700Machine Sizemm970*1130*2050Sparate Tankmm/Electrical Specification  Input VoltageV380Max.input powerKW2.5Max.output CurrentA30Max.material Removal Ratemm³/min300Min.electrode Wear Ratio
