Belfone Btx Base Station Repeater with Dmr Tier 3 Trunking Dispatch System

BF-9300 BTX (Basic-built DMR Tier 3 Trunking System)OverviewBelFone DMR Trunking System, a new generation of integrated digital trunking system based on DMR Tier III open standard, is designed for public safety, utilities, transportation, energy industry and other professional users to provide safe and reliable radio communications as well as command and control solutions. Enhanced by information technologies, BelFone DMR Trunking System is highly versatile in increasing team collaboration efficiency and enhancing safety of front-line personnel.BTX, a multimedia communication and control system based on IP network, integrates DMR trunking, video, monitoring, text, voice dispatch, etc. With soft-switching technology and distributed architecture, it achieves cross-standard/ system/ region/ department/ operator interconnection. BelFone owns patents for this comprehensive communication system of strong expansibility and high security.TopologyFeatures&BenefitsElementsApplicationProduct DescriptionBase Station BF-TR930Composed of integrated modules of control unit BSC, transmitting unit TXU, receiving unit RXU, duplex combiner COU, and power supply unit, the base station provides wireless coverage and call services for a specific area with resource allocation, call link establishment and maintenance, voice & data services and efficient command & dispatch. With independent data and control lines, all units adopt the plug-in module.Features & Benefits 19" rack structure based on ATCAHigh Integration modular design, including BCU, TRU, RCU, CDU.The standard 2 carriers (4 channels) and 4 carriers (8 channels) with channel unit (RCU, TRU) can be extended to 16 carriers.50W TRU output powerAll IP design, each unit connect with IP, ensure good reliability and stabilityThe baseband and B/S control unit adopt plug-in design, each unit is connected by independent data bus and control bus.MSC (Mobile Switch Office)The core network system is mainly used for signaling and service exchange between base stations, and external gateway such as public network gateways, PSTN, and MPT. Moreover, the device supports local hot backup and remote disaster recovery. Built for large scale systems and multiple agencies, the MSC supports a comprehensive list of feature and capabilities to meet the variety of needs of its users.    IP based architectureSystem APIFull redundancyLog serviceAuthenticationLocal MS registration and managementRoaming MS registration and managementBase station call signaling exchangeVoice or data exchange between base stationsService and signaling exchange between MSC systemSupport signaling exchange with converged gatewayMSC Server (Core Network)With PSTN/PABX Gateway interfaceWith MPT Gateway interfaceSmall and middle network design, high integrationCompact size in 19 inch, 2U, design for rack mounted and easy installationSupport single MSC and distributed multi MSC deployment, expandableSupport DMR Trunking radios switch, PSTN/Cellular phone (with integrated gateway)Integrated GatewayBased on advanced IP softswitch communication technology and digital signal processing technology, BelFone Converged Gateway is a complete IP-based multimedia dispatch solution which can support a unified communication platform to connect radios of different frequency, analog trunking, digital trunking, fixed phones, mobile phones, SIP phones, video surveillance etc., to realize rapid networking between different terminals, multimedia exchange of voice and video data, and interconnection.4G Compatible with Digital and AnalogConverged communicationIP architecture Multi-network IntegrationMultimedia ManagementHotline ButtonVoice DispatchingData DispatchingTrunking DispatchingGIS DispatchingDisaptch and NMSProduct ParametersGeneralCapacity 1Up to 100 BSs/MSC Capacity 24 carriers / BSBase Capacity256 MaxSubscribers/MSC50,000 MaxFrequency UHF 350~390 Or 400~470 MHzVotalge110/220VPower Comsumption2-carrier: ≤312W 4-carrier: ≤625WCompatible RadiosBF-SCP970, BF-TD950, BF-TD930, BF-TM950Operating Temperature-20-50 ºCStorage Temperature-40-60 ºCRelative Humidity (RH)yesSupport DispatchyesSupport DNMSyesSupport DVRSyesTransmitterOutput PowerMax. 50W/CarrierModulation Accuracy±3.15kHzOccupied Bandwidth (OBW)≤8.5kHzFrequency Offset≤±100HzIntermodulation Attenuation≤-60dBACPR (Adjacent Channel Power Ratio)≤-62dB@12.5kHzSpurious Emission (9.00kHz -1.00GHz)≤-36dBm@100kHzSpurious Emission (1.00GHz -12.75GHz)≤-30dBm@100kHzReceiverSensitivity-120dBm@BER 5%Intermodulation Response Rejection≥70dBSpurious Emission (9.00kHz -1.00GHz)≤-36dBm@100kHzSpurious Emission (1.00GHz -12.75GHz)≤-30dBm@1.0MHzReliabilityMTBF (Mean Time Between Failures)100,000 hoursMTTR (Mean Time to Repair)≤30 minutesRadio TerminalsBF-TD950 Professional Portable Trunking RadioBF-TD930 Economic Portable Trunking RadioBF-TM950 DMR TIER III TRUNKING MOBILE RADIOCompany ProfileCommunications for Efficiency and SafetyFounded in 1989, BelFone has been pioneering the development of profess
