High Efficiency Silica Gel Wheel Industrial Dehumidifier ZCB-8000

Main Parameters:  ModelZCB-8000Process Airflow(m3/h)8000Regeneration Airflow(m3/h)2670Supply Air ParametersT=15-25ºC, RH=10%-30%Regeneration ConsumptionElectric(kw)54Steam(Kg/h)110Steam Pipe(mm)DN25Chilled Water TemperatureT≤7ºCChilled Water Consumption (T/h)25Chilled Water Pipe Diameter (mm)DN50Power of Regeneration Fan(kw)2.2Power of Process Fan(kw)7.5Power of Driving Motor(kw)0.1Power Supply(V)3Phase-380V-50Hz (can be customization)Installed Power(kw)Electric Mode63.8Steam Mode9.8Inlet of Fresh Air(mm)630*320Inlet of Reflow Air(mm)630*320Outlet of Process Air(mm)800*500Inlet of Regeneration Air(mm)750*500Outlet of Regeneration Air(mm)260*228Surplus Pressure of the Unit(Pa)≤650Dimension(mm)Length5850Width1300Height1700Weight(kg)2200  Operating Principles:Supply Air StreamOutside air is drawn into the unit using the supply fan.The warm, moist outside air first passes through filters and then the cooling coil where it is cooled.The air then goes through the desiccant wheel where the air is dehumidified and the temperature is raised.At last the air is delivered directly to the space or into an existing air handler.Exhaust Air StreamExhaust air is used to provide energy recovery for the desiccant wheel and is drawn into the unit using the exhaust fan.The air filtered and then heated and humidified during the energy recovery process.The air is then heated while passing through the regeneration coil.The heated air removes the moisture that the desiccant wheel adsorbs from the process air stream.  Our Advantages:- High dehumidifying capacity- Dry air with super ow humidity can be easily obtained- It is able to supply dry air with super low dew point less than -70Celsius degree.- Its dehumidification performance is more marked under the environment of low temperature and low humidity.- Easy to operate and management, low operating cost- Long ife and durable- Complete equipment model, perfect dehumidification function- Environment protection, pollution-free  Human-machine Interface:  Refrigeration System for Option:  Application:  > War Industry, Scientific Research, Electric Power Transportation> Lithium Battery Industry, Biotechnology Pharmaceutical Industry> Chemical, Daily Chemical Industry, Food Beverage Industry> Safety Glazing Material Industry, Tyre and Rubber Industry> Medical Instrument, Vegetables Frozen, Precise Instrument> Wood Goods, Shipbuilding Painting Industry, Kinds of Storages  Certificates:  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
