Compact Non-Pressure Solar Hot Water Heater with CE Approved

Basic Info.Model NO.SLDTSStructureCompact TypeTrademarkSkylightSpecificationCEOriginChangzhou, ChinaHS Code8419191000Product Description 1) Non-Pressurized Solar Hot Water Heater (SLDTS) with CE Approved2) Manufacture since 19983) Free training, no worry4) 5-year warranty, free replacement5) One-stop solution & service6) OEM & design service offered7) 10L-600L water tank available8) AAA, BV, SGS, ISO9001-2008, CE,Non-Pressurized Solar Hot Water Heater (SLDTS) with CE ApprovedComponents:Solar evacuated tubes, solar storage tank and supportTechnical data:Skylight Evacuated Tube Specifications:1. Length (nominal): 1800mm/1500mm/2100mm/500mm/800mm2. Outer tube diameter: 58mm/47mm/70mm3. Inner tube diameter: 47mm/37mm/60mm4. Glass thickness: 1.8mm/2.0mm5. Thermal expansion: 3.3x10-6° C6. Material: Borosilicate Glass 3.37. Absorptive Coating: Graded Al-N/Al8. Absorptance: V>93% (AM1.5)9. Emittance: < 8% (80° C)10. Vacuum: P< 5x10-3 Pa11. Stagnation Temperature: > 200° C12. Heat Loss: < 0.8W/ (m2° C)13. Maximum Strength: 0.8MPa14. Start-up temperature: ≤ 25° C15. Anti hail: ≤ Ø 25mm16. Weight: 2.2kg/1.2kg/3.0kg17. Package: 1880*330*170(10PCS) 1880*280*170(8PCS)18. Sky-light Special tube like 100mm or 120mm tubes are also available against requestSkylight Tank and Frame Specifications:1) Volume: 10L, 20L, 50L, 80L, 90L, 100L, 150L, 180L, 200L, 220L, 250L, 300LInner tank material and thickness: SUS304 2B /0.5mm2) Outer shell material and thickness: Color steel/0.5mm OR SUS304/0.5mm3) Insulation material and thickness: CFC free Polyurethane/55mm4) Frame material and thickness: Galvanized steel/1.5mm OR SUS304/0.5mm5) Size of the holes: G1/2 OR G3/46) Electrical heater: Available against request, 1500W or 2000W7) Magnesium rod: Available against request8) Assistant tank: Available against request: Dia. 160mm*220mm (6L), 8L, 10L, 30L, 50L, double tank.9) Controller: Available against request: SP25, SP26, SPI, SPII, SPIII10) Sky-light Guarantee: 3 years for galvanized steel support, 5 years for solar storage tank and evacuated tubesWorking PrincipleEVACUATED Sky-light tubes are the absorber of the solar water heater. They absorb solar energy converting it into heat for use in water heating. Evacuated tubes have been invented in China by Professor Yin Zhiqiang and have already been used for years in Germany, Canada, China and the UK. There are several types of evacuated tubes in use in the solar industry. Skylight uses the most common "twin-glass tube". This type of tube is chosen for its reliability, performance and low Sky-light manufacturing cost.EACH evacuated tube consists of two glass tubes made from extremely strong borosilicate glass. The outer tube is transparent allowing light rays to pass through with minimal reflection. The inner tube is coated with a special selective coating (Al-N/Al) which features excellent solar radiation absorption and minimal reflection properties. The top of the two tubes are fused together and the air contained in the space between the two layers of glass is pumped out while exposing the tube to high temperatures. This "evacuation" of the gasses forms a vacuum, which is an important factor in the performance of the Skylight evacuated tubes.CONVECTIVE movement of the liquid starts when liquid in the loop is heated, causing it to expand and become less dense, and thus more buoyant than the cooler water in the bottom of the loop. Convection moves heated liquid upwards in the system as it is simultaneously replaced by cooler liquid returning by gravity. Ideally, the liquid flows easily because a good Skylight thermosiphon should have very little hydraulic resistance. Model Aperture Area Vacuum Tubes Capacity Packaging Measurement N.W. G.W. Loadage Container Dimension(mm*mm*mm0nsion (CBM) (kg) (kg) Dia. Length No. inat.com          Skylight-Sunlight Lovet New Energy Co., Ltd )       Tank/Frame1/Frame2       20GP 40GP 40HQ SLDTS-14 1.73 m2 58mm 1800mm 14 104.3 L 1310*500*510/1540X105X45/825X525X65 0.54 61.6 67.2 46 100 126 SLDTS-16 1.96 m2 58mm 1800mm 16 118.5 L 1460*500*510/1540X105X45/825X525X65 0.64 68.8 75.2 39 84 106 SLDTS-18 2.23 m2 58mm 1800mm 18 133.3 L 1610*500*510/1540X105X45/825X525X65 0.7 75.6 82.8 36 77 97 SLDTS-20 2.48 m2 58mm 1800mm 20 147.5 L 1760*500*510/1540X105X45/825X525X65 0.76 82 90 33 71 89 SLDTS-24 2.98 m2 58mm 1800mm 24 176.5 L 2060*500*510/1540X105X80/825X525X85 0.9 94.8 104.4 28 60 76 SLDTS-30 3.73 m2 58mm 1800mm 30 220.3 L 2510*500*510/1540X105X80/825X525X85 1.06 114 126 24 51 64 SLDTS-36 4.46 m2 58mm 1800mm 36 263.8 L 2960*500*510/1540X105X80/825X525X85 1.22 131.4 145.8 20 44 56
