Water Bottling Filling Labeling Packing 3 in 1 Machine Cartoon Packing Equipment

The machine can arrange the products according to the requirement of the package. It has the advantage of wide application, especially can combined with the packing assembly line, easy move, computerized, easy operation and stability. It is suitable for packing bottle, carton, Cans, etc. Detailed Photos  Packaging part: bottle separator pneumatic bottle separator Drop bottle device pneumatic drop bottle Box drop device servo box drop The delivery system uses servo motor to drive the chain delivery Carton bonding device adopts the combination of imported hot melt glue machine spray and pneumatic pressing   Bottle conveying part: The conveyor belt is composed of thermoplastic material chain plate with low friction coefficient, which is continuously fed into bottles and guided by separate lanes Detect the empty bottle/missing bottle at the point of entry Paper feeder: Paper sucking device adopts vacuum suction cup drawing board imported from Germany The paper feeding device adopts the combination of pneumatic push and motor transport (with anti-rebound device).   Product ParametersPower supply, total powerAC380V 10KWExternal air source4-6kgf/cmActive servo electricity price380V 3000WMaster switchSchneiderUp and down servo motorSchneiderMachine size7000*2830*2016Packing speed of workpiece20 boxes/minSuitable for bottle typeglass bottles, plastic bottles, metal cans, etcSuitable for bottle diameterØ60-Ø98The machine weighs3500KGThe best working temperature-10ºC~40ºCAdequate inventory of parts. In order to reduce the cost of customer's parts inventory and provide better and faster service, our company always has sufficient equipment parts as inventory, so that at any time when you need parts for repair or maintenance, you can quickly provide. Training plan: Professional technical training, in order to ensure that your technical personnel can correctly grasp the performance, operation and maintenance procedures of the equipment, in addition to the normal installation site technical training, we can also hold all kinds of professional training, to help users more quickly and comprehensively master the technology.   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
