Flat Plate China Solar Water Heater Made in China

SPFP -ALANOD/0.6- AL/AL-80ALANOD - Aluminum Grid type plate from ALANOD company 0.6-Rated pressure 0.6MpaAL-aluminum core AL-alumnium heat tube and riser tube ModelSPFP -ALANOD/0.6- AL/Cu-80Outline area2 m²Aperture area1.89 m²Absorption area1.82 m²Dimensions2000*1000*80NW33/34kgCapacity of cooper pipe2.3LTransparent coverOrdinary fabric surface tempered glassAperture rate≥91%Thickness transparent cover 3.2mmAbsorber materialAluminum plate from AlanodThickness of Absorber Aluminum 0.40mmHeat absorption rate95±2%Emission rate 4±2%Welding technics between copper pipe and absorberlaser welding from Bluetec (spot welding double pitch 3mm)Head tubescopper tubeRiser tubes copper tubeinsulation materials 40mm Fiber glassSide Insulation thickness20mmAlloy frame material Aluminum-magnesiumFrame colorblack, bronze, silver and white Backplate materialsGalvanized sheetBackplate thickness0.5mmSealing materialEPDMHeat MediumPure water or glycol medium Testing pressure of inner circulating1.2 MpaWorking pressure of inner circulating0.6MpaInstruction angle30- 90°(Min-Max)operation temperature200ºCOur advantages:Our products process:  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
