Compact Pressure Heat Pipe Solar Water Heater (Silver PVDF Plate)

Heat Pipe Solar Water Heater 1.18years manufacturing experience 2. CE certificate, passed ISO9001 3. Simple structure, easy for assembly and installation 4. Long lifespan, more than 15years Heat Pipe Solar Water Heating 1) Copper heat pipe and inner medium for thermal transmission, with a quick startup and super efficiency 2) No water flows into vacuum tubes, system works well with withdrawal of one or several heat pipe vacuum tubes 3) Super efficiency of insulation with polyurethane foam; No vent with less heat loss as compared to nonpressurized type 4) Withstand pressure more than 6 Bar, can be connected directly with tap water, more safe system and comfortable water use. 5) Can be equipped with auxiliary electric booster and intelligent controller for automatically control 6) Simple structure, easy for assembly and installation on different structure 7) Can be used all year round even works well in extremely cold climate 8) Long lifespan, can be of good service more than 15 years Heat Pipe Vacuum Tube: Tri-target glass tube and heat pipe and its inner medium together makes an efficient solar collecting and heat exchange, efficiency generated about 55% in summer and 42% in winter more than that of all-glass vacuum tube. Inner water tank: Thickened food-grade SUS304-2B stainless steel as storage tank keeps the water clean and drinkable, advanced automatic argon-arc welding technics ensures a very long lifespan (more than 15 years) Water tank shell: Imported color steel plate or ocarbon plate (PVDF), more durable and appealing with outer special coating, and survives long (over 10 years) to ocean coast envirionment. Insulation Layer: Germany-imported polyurethane integrated foam-forming with twice slaking treatment, preserves hot water constantly as long as 70~80 hours Supporting Bracket: Galvanized steel plate, outer power coating or pain baking process, good weight bearing and wind resistance design (140 km/hr), super mechanical performance and corrosion resistance ensures a long life to acid rain, easy installation, universal bracket suitable for either flat or slope roof installation Accessories: Stainless bolts & nuts, anti-aging dustproof rubber seal, plastic pipe holder to ensure their lives as long as other parts of the system Optional Devices: Electrical heater, as an auxiliary heating element in case of raining or snowing days so as to ensure a continous hot water supply Intelligent controller, automatically controls water refill and startup of auxiliary heating device, more intelligent operation Anod magnesium bar: Soften the hard water in system so as to protect the storage tank from water scale Warranty: 3 years international responsibility for integrated system and 15 years for vacuum tubes due to original quality problems       Vacuum tube  Spec. (mm)  Φ 47× 1500        Φ 58× 1800         Tube (pcs)  15 / 16 / 18 / 20 / 24 / 30 / 36  Material  Borosilicate glass, magnetron spluttering selective coating  Coating  AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN    Water tank  Capacity  100 ~ 500L for inner water tank  Inner tank  Food-grade stainless steel SUS304-2B  Insulation  Imported polyurethane integrated foam-forming 50~60mm  Tank shell  Silver PVDF Plate    Bracket  Spec. (mm)  1.2 ~ 1.5mm in thickness  Material    Hot-dip galvanized steel plate    Accessories  Stainless bolts & nuts,   Silicon rubber seal, Dustproof rubber seal,   Plastic pipe holder  Optional  device  Electrical heater, Intelligent controller / Assistant tank, Anod magnesium bar      Tilt    angle  25° ~ 50°    Water output  45-95 o CHail resistance  Φ 25mm  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
