API 6A Well Control Safety Control Valve for Oilfield Manifold

API 6A Well Control Safety Control Valve for oilfield manifoldHigh pressure oil enter into the empty cavity of upper operator, and compress the spring of lower operator to open the valve, when the wellhead equipments suffer from dangerous pressure, control system relief the pressure of cylinder after receiving the signal sent by sensor, spring push stem to close valve and wellhead equipments, ensure the equipment safety.• When oil & gas is leaking or firing, used for security protect on well site.• Have hydraulic safety valve and pneumatic safety valve per different driving source.• With heat sensitive and high pressure explosion-proof equipment.• Have two parts of actuator and preparation valve, can replace and repair standard interface.Surface safety valve (SSV) is a pneumatically or hydraulically actuated fail-safe gate valve for producing or testing oil and gas wells with high flow rates, high pressures, or the presence of H2S. The SSV is used to quickly shut down the well upstream in the event of overpressure, failure,blockage,a leak in downstream equipment, or any other well emergency requiring an immediate shut down.Product Namesafety valveWorking Pressure2000PSI~20000PSINominal Bore1.13/16"~7.1/16" (46mm~180mm)Working Mediumoil,natural gas,mud and gas containing H2S,CO2Working Temperature-46°C~121°C(Class LU)Material ClassAA,BB,CC,DD,EE,FF,HHSpecification levelPSL1-4Performance RequirementPR1-2/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
