Lithium Battery Low Dew Point Industrial Desiccant Rotor Dehumidifier

Main Parameters:  ModelZCH-6000Process Airflow(m3/h)6000Supply Air ParametersT=15-25ºC, RH≤1%), Dew Point TL≤-60ºCPower of Process Fan(kw)7.5Surplus Pressure of the Unit(Pa)≥500Power of Regeneration Fan(kw)1.5Surplus Pressure of Regeneration (Pa)≥300First Rotor RegenerationElectric (kw)12Steam (Kg/h)24Second Rotor RegenerationElectric (kw)24Steam (Kg/h)48Steam Pressure(mPa)0.4Installed Power(kw)Electric Mode45.2Steam Mode9.2Power Supply3Phase/380V/50HzCooling Load(kw)90DimensionLength(mm)7500Width(mm)1745Height(mm)1825Weight(kg)2200  Operating Principles:Supply Air StreamOutside air is drawn into the unit using the supply fan.The warm, moist outside air first passes through filters and then the cooling coil where it is cooled.The air then goes through the desiccant wheel where the air is dehumidified and the temperature is raised.At last the air is delivered directly to the space or into an existing air handler.Exhaust Air StreamExhaust air is used to provide energy recovery for the desiccant wheel and is drawn into the unit using the exhaust fan.The air filtered and then heated and humidified during the energy recovery process.The air is then heated while passing through the regeneration coil.The heated air removes the moisture that the desiccant wheel adsorbs from the process air stream.  Our Advantages:- High dehumidifying capacity- Dry air with super ow humidity can be easily obtained- It is able to supply dry air with super low dew point less than -70Celsius degree.- Its dehumidification performance is more marked under the environment of low temperature and low humidity.- Easy to operate and management, low operating cost- Long ife and durable- Complete equipment model, perfect dehumidification function- Environment protection, pollution-free  Refrigeration System for Option:  Application:  > War Industry, Scientific Research, Electric Power Transportation> Lithium Battery Industry, Biotechnology Pharmaceutical Industry> Chemical, Daily Chemical Industry, Food Beverage Industry> Safety Glazing Material Industry, Tyre and Rubber Industry> Medical Instrument, Vegetables Frozen, Precise Instrument> Wood Goods, Shipbuilding Painting Industry, Kinds of Storages  Certificate:  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
