Automatic Pressure Welder Steel Frame Lattice Welding Equipment for Steel Grating

Design basisSteel grating max width & length:995mm &6000mm can be customizedFlat bar width(height): 20mm -60mmFlat bar pitch: 30,40mm, can be customized.Twisted bar pitch: 50, 100mm, can be customized.Flat bar thickness: 2-6mm can customizedTwisted bar : 5x5mm, 6x6mmThe size from end of flat bar to first cross bar is settable, Inclusive of all necessary assemblies from Bearing bar feeder to finish grating conveyer on output side.Product DescriptionThe machine is to finish flat bars and square twisted steel welding automatic machine.It is single phase AC input, the power grid will be not balance, the welding current is AC. 1,Easy to operate and display clearly. By means of terminal man-machine interaction can achieve functions following: real-time monitor machine's performance; set line rod pitch and number; record numbers of work-piece.2,Transformer is made by superimposing silicon steel sheets which are high quality and imported. Transformer has internal water cooling, casting by epoxy resin and has the function for warning of over-temperature.3, There is function for fault self-monitor, displaying on the LED screen.4, Very strong protecting functions: non-water and insufficient water pressure, transformer over-heat SCR over-heat, over-big current and over-load.Applications: the platform of such trades as petroleum, chemical industry, electron, quay, municipal administration, environmental protection, national defence etc.Functions1, Press welder equipped with 4 column hydraulic machine, Max pressure 160 ton and adjustable2, welding power source is DC3, Twisted bars are ordered position by manual but feed by automatic4, Flat bars are located by manual but feed by automatic5, Steel grating is transported automatically6, Weld two bars for each time automatically, pitch of twisted bars can be controlled automatically.7, Deformation for longitudinal welding is corrected automatically.8, Operation station is with both manual and automatic type.9, Electrical cabinet is with display device for current and voltage.10, Welding parameters can be set and saved, don't lose even if outage. Parameters is displayed as digit.  Product Parameters ModelGYH-630-2A-1GYH-800-2A-1GYH-1000-2A-2GYH-1600-2DPower sourceACInveter ACInveter ACDCWelding capacity630kVA800kVA1000kVA1600kVAInput voltage3 phase 380V/50Hz3 phase 380V/50Hz3 phase 380V/50Hz3 phase 380V/50HzSteel grid plate length6000mm(customized)6000mm(customized)6000mm(customized)6000mm(customized)Steel grid plate width1000mm(customized)1000mm(customized)1000mm(customized)1000mm(customized)Flat bars center distance30,40mm(customized)30,40mm(customized)30,40mm(customized)30,40mm(customized)Maximum touch area of each twisted bar with flat steel800mm21000mm21250mm22000mm2allowable width  of flat steel20--60mm20--60mm20--60mm25--75mmallowable thickness of flat steel2--4mm2--5mm2--6mm3--7mmtwisted bars5×5,6×65×5,6×65×5,6×65×5,8×8Function of deviceSingle cylinder with four columnSingle cylinder with four columnSingle cylinder with four columnSingle cylinder with four columntwisted bar number for each welding process2222Maximum pressure of welding machine75T75T100T160TFeed mode of loading flat steelAutomatic droppingAutomatic droppingAutomatic droppingAutomatic droppingFeed mode of twisted barsManual align, automatically feed-inManual align, automatically feed-inManual align, automatically feed-inManual align, automatically feed-inStepping way of welding steel grid plateReciprocating pullingReciprocating pullingPulling all the wayPulling all the way  Detailed PhotosCompany ProfileWe, Ningbo Xin Chang Machinery Co.,Ltd are a professional designer and manufacturer in friction welding machine, resistance welding machine and Heat exchanger equipment. Our factory is in this line more than 20 years, we have more than 10 senior mechanical and electrical specialists and total more than 200 staff, our machine is famous in China. We have CCC, ISO9001 and CE certificates.   Over the years, we have exported so many machines to 30 and more countries, such as France,Spain,Poland,Russia,Indonesia,Vietnam,Pakistan,India,Mexico,Egypt etc. Our main products are Heat exchanger equipment, Friction welding machine, spot welding machine, projection welding machine, butt welding machine, seam welding machine, multi head welding machine for wire mesh, and other various special welding machine for metal connection in different industries. We always adhere to the management idea of "Integrity, profession, innovation, and win-win", to make Xin Chang becomes trustworthy enterprise of customers. Good product quality, perfect after-sales service, and professional technical support make customers choose no regrets and worry-free use.FAQ1.Q: What about your standard delivery date ?    A: Usually 30-60 working days. Our company provide just-in-time delivery2.Q: How can you guarantee quality?   A: You could test samples before order,and we have professional QC and precise machining equipment; Always final Inspect
