750ton Bucket High Speed Injection Molding Machine

  China servo injection molding machine.  A. modulus of capacitance: The position, size, and maximum allowable modulus of capacitance and minimum closure thickness of the injection molding machine guide pillar (Green column).standard injection molding machine manufacturer B .nozzle parameters: spherical diameter of the nozzle, nozzle aperture, nozzle outer diameter, maximum nozzle extension length, positioning aperture.standard injection machine.C. code mold parameters: code mold hole, slot size.ce standard injection molding machine.D .Ejection mechanism: The position of the ejection point and the diameter of the ejector rod, and if necessary, the ejection force and ejection stroke are also provided.E. Mold opening stroke and maximum opening distance.plastic injection machine   Model UP-750TInjection UnitA BCScrew diameter (mm)100110120Shot Volume    (cm3)363644005236Injection weight  (g)330640034765injection pressure (Mpa)184152128Screw speed   (rmp)110Clamping Unit   Clamping force  (KN)7500Open stroke  (mm)980Max Mold height   (mm)1000Min Mold height   (mm)400Space between tie bars(mm)980*950Ejector force  (KN)185Ejector stroke  (mm)260Others   Pump pressure  (Mpa)16Motor/driving power  (KW)37+30(39.5+36.7)Heating power (KW)56.7Machine dimension  (M)10.8*2.3*2.9Machine weight  (T)42Oiltank cubage  (L)1600FAQ1: Are you a trading company or a manufactory?  We are a manufactory, we supply the factory price with good  quality, welcome to visit !2:Do you have QC or any safety standards for your plastic injection molding machine?  yes,we have established a highly strict quality control department  to guanrantee good quality.3:Why choose our plastic injection molding machine?  High quality with competitive price4::How about quality control in your factory?  "Quality is first, Customers are friends".5:Can you help us with the shipment of this machine ?  Yes , with honor ,we have our special shipment company which  already cooperate     /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
