Shanghai Cixi Delta Control Pressure Switches

Brief introduction 1. This model intelligent pressure switch is a kind of intelligent digital pressure control products 2. It integrate pressure measurement, LED display and control. 3. It is complete electronic structure, the former adopt pressure sensor which is diaphragm, oil fulfill and piezoresistive type. 4. Application: Measure the gas and liquid. Suit for pump control, tank monitoring, level control, filter plug, monitoring, leakage monitoring. Also it widely used in hydraulic and pneumatic situation, like mechanical facility and process control. Main features 1.4 digits display the current pressure value, pressure preset switch point and delay switch output. 2. Switch signal can be set it randomly between zero and full scale. The housing have LEB with node action. 3. Easy to observing key-press calibration and the parameter's setting in field. Convenient operation. The overload capacity is 1.2A for 2 channels switch signal output. 4. Analog output (4-20Ma), the measurement range: 0-600bar (Option) Most Accurate Control By Electronic Thermal Mass Water Flow Switch                                    -----------We are gold supplier in 9 consecutive years     CX-FS series Electronic thermal mass  flow switch , also known as differential thermal flow sensor and Thermal flow sensor . The set range can be 1-20m/s . Have relay output (230VAC.4A). Suitable for different kinds fluid .Concise and direct indicator ,and with high reliable .     The Principle of electronic thermal mass flow switch based on the principle of thermal theory, there are two resistances in the closed probe . One resistance was heated and regarded as detected resistance , the other one was heated and regarded as standard resistance . When the medium is flowing ,the heat on the heated resistance will be taken away and the resistances' value will be changed . The differential resistances value is the basis of determining the flow velocity .Application:gaseous /liquidThe flow switch for ground-source heat-pump is mainly applicable to industrial automation/mechanical equipment/air compressing industry/ refrigeration and air-conditioner. The magnet not contact with flowing water, so can normally work in sewage discharging system. CX-FS-FB Paddle Flow SwitchDiameterDN25…DN150Set range20…1800L/min(water)Repeatability±2.5%FSConnectionterminal typeOutputMechanical switch  NO+NC(250VAC,3A)Pressure proof16 barAverage pressure loss:0.08bar( at max.flow rate)Ambient temperature-25…80CMedium temperature0…90CInterface screwG1"pipe screwProtective classIP33Weight0.55kgMaterialMain bodystainless steelProcess connection:brassConnection rodbrassBafflestainless steelSeal NBRHousingABSCX-FS-FB12 Baffle Flow SwitchRepeatability±2.5%FSConnectionterminal typeOutputMechanical switch  NO+NC(250VAC,3A)Pressure proof16 barAverage pressure loss:0.08bar( at max.flow rate)Ambient temperature-25…80ºCMedium temperature0…90ºCInterface screwG1"pipe screwProtective classIP33Weight0.85kgMaterialMain bodystainless steelProcess connection:brassConnection rodbrassBafflebrassSealNBRHousingABSCX-FS-FPD20 Pointer display type piston flow switchMediumliquid or gasRepeatability≤±3%full scalePressure200bar(stainless steel type)100bar(brass type)Outputnormally open outputContact capacity240VAC / 110VDC 1.5AAmbient temperature-20…70ºCMedium temperature0…70ºCProtectionIP65OutletM12*1MaterialElectronic bodyPCSwitch bodystainless steel / brass nickel platingSpringstainless steelCX-FS-FR11 Electronic Flow SensorSet range1…150cm/s( water),3…300cm/s(oil),20…2000cm/s(air)OutputPNP, NPN, Relay ,4-20mA, NO+NC (SPDT)Power supply24V±20%DC or 230V±15%ACSwitching CurrentMax.400mA(PNP or NPN type ), Max.4A( Relay type )Unload currentMax.80mAFlow indicatorLED (6)Set typepotentiometer setProof Pressure range100barTemperature gradient4ºC/sResponse time1--13s,standard is 2sInitialization time8sElectrical protectionreversed-phase ,short circuit ,overload protectionProtection classIP67Medium temperature20--80ºCEnvironment temperature-20--80ºCStorage temperature-20--100ºCConnectionM12 connector /2m cable (option)MaterialProbe is stainless steel . Housing is PBTWeight0.4kg  CX-FR-FR12 Electronic flow switchSet range1…150cm/s( water),3…300cm/s(oil),20…2000cm/s(air)OutputPNP, NPN, Relay ,4-20mA, NO+NC (SPDT)Power supply24V±20%DCSwitching CurrentMax.400mA(PNP or NPN type ), Max.4A( Relay type )Unload currentMax.80mAFlow indicatorLED (6)Set typepotentiometer setProof Pressure range100barTemperature gradient4ºC/sResponse time1--13s,standard is 2sInitialization time8sElectrical protectionreversed-phase ,short circuit ,overload protectionProtection classIP67Medium temperature20--80ºCEnvironment temperature-20--80ºCStorage temperature-20--100ºCConnectionM12 connector /2m cable (option)MaterialProbe is stainless steel . Housing is PBT  ModelConnectionNotesAccuracyHFS-251″-11½NPT ScrewRed Case5%HFS-20¾″-14NPT ScrewHFS-15½″-14NPT ScrewJYF-251″-11½NPT ScrewWhite Case2-3%JYF-20¾″-14NPT ScrewJYF-15½″-14NPT ScrewRated
