XCMG 18m Truck-Mounted Concrete Delivery Pump (HPC30KI)

XCMG 18m Truck-Mounted Concrete Delivery Pump (HPC30KI).  1. The lengthening two-stage telescoping boom can realize the max. spraying height of 18m, the farthest front spraying distance of 14.8 and wider spraying range.   2. Swing boom at end is innovatively designed and matched with a spraying mechanism of three DOF and a remote controller with universal joystick to realize more flexible spraying operation without dead angle and meet tunnel construction requirements to the greatest degree.   3. By incorporating Schwing's fully-hydraulic reversing technology, short reversing time, small spraying impulse, low rebound ratio and good spraying planeness are realized.   4. Besides the main power by motor, chassis power can realize boom and outrigger telescoping without access to electricity and condensing agent feeding into IBC-tank; the simultaneous operation of pumping system and high-pressure water pump ensures more convenient and efficient cleaning of overall machine.   5. Quick-open type design can easily realize replacement of delivery pipe, product maintenance and lubricant adding, etc.Product ParametersDescriptionUnitHPC30KI Traveling system Overall weight kg 16000 Outline dimension (L×W×H)(Incl. conveying pipe) mm 9360×2500×3660 Rated power of engine kW/rpm 132 /2400 Emission standard of engine   China V Gradeability % 30 Turning radius m 9.5 Max. speed/hour km/h 90 Spraying system Max. spraying height m 18 Max. spraying width m 29.6 Max. front spraying distance m 15 Min. permissible tunnel height for spraying operation m 4 Max. operation depth m 7 Axial rotation of nozzle seat ° 360 Axial swing of nozzle seat ° 240 Nozzle brushing along deflection angle X ° 8×360 Pumping system Max. theoretical spraying capacity m3/h 30 Max. pumping pressure MPa 8 Concrete cylinder diameter/stroke mm 180/1000 Hopper capacity L 500 Max. permissible aggregate diameter (pumping/spraying) mm 22/16 Burdening type   Rock valve Air compressor Volume of air supply m3/min 10.5 Air pressure MPa 0.8 Accelerant agent Delivery pressure MPa 0.8 Accelerant weighing/delivery capacity l/h 60~600 Product ShowCompany ProfileFAQ1: What kind terms of payment can be accepted?A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted2: What certificates are available in Machinery?A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,3: What about the delivery time?A: 30 days after receiving the deposit.4: What about the warranty time?A: 12 months after shipment or 2000 working hours, whichever occuts first.5. What about the Minimum Order Quantity?A: The MOQ is 1 pcs.  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
