Concentric Awwa Double Flanged Valve with Ce ISO Wras Acs Approved

Product Feature:        Resilient seated butterfly valve is a Double  Flanged design which can be used for dead-end service. This butterfly valve series has many of the design features and benefits , such as high Cv ratings, minimum parts exposed to the line media, greater reliability and a proven record of long service life. A major design advantage of this valve product lines is international compatibility.Material :BODY CI, DI, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, C95400, C95800, SAF2205, SAF2507, F51, 1.4529^^DISC  CF8, 304, CF3, 304L CF8M, 316, CF3M, 316L, SAF2205, SAF2507, F51, 1.4529, C95400, C95500, C95800, MONEL^..SEAT BUNA-N, NBR, EPDM, HYPALON, NEOPRENE, VITON, FKM, PTFE, RPTFE, TEFLON, NATURAL RUBBER^^STEM F410, F420, F430, F431, F304, F316, MONEL 400, MONEL K500^^Technical Parameters:SizeDN32-DN600DN650-DN3000Working pressure16Bar10BarShell24Bar15BarSeal(Air)6Bar6BarOperating Temperature-40ºC~+160ºCOperating EnvironmentBallast and bilge system          Chemical processingDesalination plants   Drilling rigs    Drinking waterDry powder     Food and beverage     Gas plantsHAVC  Mining industry  Paper industry    Sand handling     Seawater    Sugar industryThermo technical water treatment   Waste waterDriving  methodHand  Lever  Worm Gear  Electric  Pneumatic**COMPANY INTRODUCTION **Company Goal : OEM service for world-famous valve brand **Design & Development ability -- SolidWorks, Pro / E, AutoCAD etc **Dimension Measurement &Inspection  **Assembly Workshop **Packaging  **Certificates --  CE  ISO  WRAS  ACS certificates /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
