J24W Flanged Angle Type Needle Valve

J24W Flanged Angle Type Needle ValveProduct Description Needle valve is a type of valve that can be precisely adjusted and has a wide range of applications. For example, the cutting distance used for flame cutting, the knob used to adjust flame temperature is the needle valve, and the instrument needle valve is an important component of the instrument measurement pipeline system, mainly including globe valve and ball valve. Its function is to open or cut off pipeline paths. SpecificationSpecification:1. Design: GB/T12224-2005  JB/T7747-1995 2. Connection: NPT,G,Rc,Rp 3. Test:  JB/T9092-1999 4. Nominal Pressure:≤10000Psi 5. Applicable Temperature:-29ºC~+538ºC 6. Applicable Medium:,, 7. Nominal Diameter:DN6,DN10,DN15,DN20,DN25 Product DetailsMaterials of main parts     Part NameBody,BonnetStem,DiscPackingJ24W-160P-DN3Chromium nickel stainless steelStainless steelPolytetrafluoroethylene, flexible graphiteJ24W-320P-DN6High quality carbon steelChromium nickel stainless steelPolytetrafluoroethylene, flexible graphiteMain External Dimensions.    ModelNominal Diameter DN(mm)SizeWeight(Kg)L1DoD2HH1D1J24W-160P-DN3380651591701431.0J24W-320P-DN6680651591701461.0Product ParametersModel TypeNominal Pressure(MPa)Test Pressure PS(MPa)Working Pressure (MPa)Working Temperature(ºC)Applicable MediaHousingSealing(liquid)Sealing(gas)J24W-160P-DN316.024.017.60.616.0P≤200ºCLiquefied petroleum gas, water, oil products, etcJ24W-320P-DN632.048.035.20.632.0C≤425ºCView of the factory     /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
