Ductile Iron Flanged Ends Tilting Disc Check Valve with PN10 PN16Tilting Check Valve PN10 PN16 DN300-DN1200Cast Iron Double Disc Wafer Type Check Valve CHECK VALVESTilting Disc Check Valve Tilting Check Valve PN10 PN16 DN300-DN1200 PRODUCTION STANDARDS Design: EN12234Face to Face Dimension: DIN3202 F4Flange: EN1092-1Working Pressure: PN10PN16Shell Test:1.5Mpa2.4MpaSeat Test1.1Mpa1.8MpaApplication:Water/ SwageTest StandardDIN32320FEATURES• Tilting Check Valve, while allowing the flow moving to the desired flow direction,stops the flow when exposed to back flow • With the start of movement at defined flow direction on the system, the disc leaves the flow section by turning in its axis and allows the flow pass. • When the flow stops, the disc sits on the machined sealing seat through by force of extra weight and maintains 100% tight sealing. • The body and the disc can be manufactured as cast iron and ductile iron and sealing seats are manufactured .from stainless steel • Hydraulic brake system can be assembled to disc closer unit if it is required at project.The rate of closure can be controlled due to tilting check valve with hydraulic brake system and the system passes to static position slightly. The installation equipment protected from impact strength. APPLICATIONSSteam, superheated water, hot water, cold water, fluids without acidity or alkalinity properties, chemicalsTEMPERATURE+140 °COther productsWhy Choose USOur factory is specialized in valves' production. As one of the biggest and most professional manufacturer and exporter majored in valves, we assure that we can provide our products with cheapest price, good quality and best service. If you like, welcome to our factory and have a look!We test leakage of each roll before braiding, then we cut 300mm and crimp it to testburst pressure after brading.We use CNC Lathes Machine for end fittings production. Machine system, knife and inspectiontools are all imported from Japan.We use Techmaflex Crimping Machine which is imported from France. This machine hasaccurate and stable performance for crimping because it is produced for PTFE hose crimping only.Contact to this supplier http: xbvalve.en.made-in-china.com www.xbvalve.net/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
