Easy to Operate and Automatic Control Oxygen and Nitrogen Production Plant

Product Description  Differ from Pressure swing adsorption process (PSA) process, we adopt Cryogenic distillation process for making the air separation plant. With this process, pure gases can be separated from air by first cooling it until it liquefies, then selectively distilling the components at their various boiling temperatures. It can produce high purity gas product.  KZON-80/80 Type Air Separation Plant is a cryogenic oxygen and nitrogen producing machine which can produce high purity Oxygen or high purity nitrogen in different working condition. One machine with two functions, while providing customers with high-quality gas products, it also saves costs for customers. Customers can adjust the production mode according to the actual gas market conditions to meet market demand.Product ParametersThe main parameter about KZON-80/80 air separation plant is as following:Performance SpecificationModeWorking conditionProductFlow ratePurityKZON-80/80 IO280Nm3/h≥99.6% IIN280Nm3/h≥99.99%Reference utilities consumption based on design mode Reference installed motor power on design mode152KWCooling methodAir coolingWorking pressure≤1.2MpaStart-up time6~8hPlant shutdown for scheduled maintenance≥ 24 monthsDetailed PhotosAir compressor  The inlet air will be compressed into the pressure as per process required.  It is sprayed-oil screw compressor, box-body construction, it have low noise, whole machine gather gas, lubricate, water, electric, cooling and instrument to one, realize machine and electric become one body.Pre-cooling unit  The outlet temperature of compressed air is around 40ºC which is too high for the down-stream molecular sieves high efficiency operation, in order to increase the performance of the molecular sieves, a pre-cooling unit is required. Purifier  Remaining contaminants in the process air such as moisture, carbon dioxide, acetylene (and etc.) shall be removed before enters into the main heat exchanger, a molecular sieves system is adopted.Turbine expander  Turbine expander also referred to as a turbo-expander, is a centrifugal or axial-flow turbine, through which a high-pressure gas is expanded to produce work. It's the one of core part of the whole plant.Fractionating column  It adopt fin type heat exchange, made in aluminum, heighten heat exchange affection, depress the operating pressure, reduce the power consumption furthest, saving cost.Liquid pump  Liquid pump is a kind of cryogenic liquid pump, by which the pressure of oxygen/nitrogen can be increased to achieve the purpose of transporting oxygen/nitrogen.CertificationsIn order to improve equipment performance and provide customers with better products, our company has established a research and development center. After continuous research and creation, combined with market demand, we have invented many devices to improve equipment performance. The following is a partial display of our invention patent certificate:Packaging & ShippingAll equipments are packed as required as transportation standard.Our AdvantagesAll unit machines are skid-mounted construction, connected by fixed-size short pipe, it's not complicated to install.Adopt liquid oxygen pump inner-compress technology, could produce  high-quality oxygen, which can be used both for medical and industrial filed.Complete set plant runs stablly, and it's easy to operate, convenient to maintenance, and we supply a two-year spare parts freely.Set four-stage pipeline oil-removing filter with imported filter element. Each filter element shall be replaced with a monitor to remind users to replace the filter element regularly, preventing the oil and water in the air from entering the purifier and fractionating tower. Design and manufacture of the external cleaning tower system of the fractionating tower, no need open to clean the oil in the fractionating tower, avoiding the trouble of removing and reloading perlite, cutting and welding aluminum pipes and leak detection.All the fractionating tower is filled with waterproof pearlite (perlite), which ensures the start-up time of normal oxygen production due to its excellent cooling effect.Related productsFAQQ1: What is your company specialized in?   -We're a professional engaged in air separation plant, dissolved acetylene plant, chemical tail gas recycling equipment, food grade CO2 equipment, liquefied natural gas equipment, design, research and development, manufacture and after-sales service as one of technological innovation-oriented enterprises. Q2: Are you a manufacturing factory or trading company?   -We are professional manufacturer. Q3: Where is your factory located?   -We're located in Shenglong industrial park, Handan city, Heibei province of China. Q4: Can I come to your factory to observe machine running? Can you arrange driver to pick me up?   -Yes, we welcome you to visit our factory and if you come, we'll arrange driver to pick you in the train station or airport. Q5: Where do you sell your product/what is your major mar
