Dynamic 500kw Biomass Gas Generator

 Worksite requirements:The worksite needs to meet following basic requirements:a)  ambient temperature between -40ºC~40ºC;b)  Relative humidity less than 95%(35ºC);    c)  Site elevation not higher than 2500m;d)  For outdoor installation, rain shelter is requiredTechnical data sheetManufacturer Dynamic EnergyGenset model 500GFZ1-PWJEngine model G12V190ZLDK-2AAlternator model 1FC6 454-6LA82-ZBreaker panel model GCBP1Field control panel  FCP1Local control panel (Optional) LCP1Rated powerkW500Rated currentA902Rated voltageV400Rated power factor  cosφ0.8 (lagging)FrequencyHZ50Fuel gas consumptionMJ/(kW·h)10Lubricant consumptiong/(kW·h)≤0.8Electrical efficiency%36Start-up method DC 24V Electric motorStart-up control   Manual/AutomaticWiring method 3 phase 3 line/3 phase 4 lineStable speed droop %≤5Cooling method Closed loop, with fan radiatorExhaust back pressure max.  6 kPaNoise level 105 db @ 1 meter away from the gensetGenset vibration ≤7.2mm/sCoupling between engine and alternator Directly coupling (single shaft), with elastic couplerDimension (L×B×H)mm5433X1970X2700Weight kg11200Major component/system supplier & description:Overall genset managementDynamic patent TEM3 gas engine control system;+ ComAp power control module;+ Altronic/Motortech ignition system;+ Heinzmann Pandaros/Orion speed governing system.Air/ fuel ratio controlDynamic patent TEM3 gas engine control systemSpeed governing system (digital)Heinzmann Pandaros orHeizmann OrionIgnitionAltronic digital ignition system or Motortech digital ignition systemIntelligent circuit breakerChangshu Switchgear orTianshui 213 As a professional gas engine manufacturer, Dynamic Energy provides ideal power source for your different purposes, including power generation, compressor driving, etc.    /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
