Kemper Style Hammerseal Union Seal O Grip Union Hammer Union

BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges. BETTER manufactures and supplies unions for mud tanks, Hammerseal Unions, mud tank connecting lines and pump suction flanges. These are manufactured for a maximum line pressure of 150 PSI. The nitrile seal provides compressive seal, the cross-section of the seal designed to provide greater sealing surface. The union is designed to take a maximum of 7° misalignment on the pipe. Sizes which are catered for are 6", 8", 10" and 12", 6", 8" and 10" sizes can be socket welded to pipe or butt welded to tubing. 12" size requires butt weld. BETTER Mud Tank Union is an updated design based on Air Grip Unions. These tank unions can accept pipe misalignment to finish an excellent connecting and sealing, and installation and uninstall rapidly, which has been widely used in mud tanks, mud tank connecting lines, and pump suction flanges.Both of BETTER Air Union and Tank Union styles are interchangeable with other major brands, Bulldog, C&C Industries, Kemper.FeaturesElongated cross-section of seal ring ensures greater sealing surface when in contact with the pipe makes up with hammerMolded nitrile seal provides a compression sealTank union accepts up to 7 degree pipe misalignmentAvailable in3, 4, 6, 8, 10, 12, 14, 16, 18 and 20 inch sizesPart no.: PS300A, PS400A, PS600A, PS800A, PS100A, PS120A, PS130A , PS140A, PS160A, PS180A, PS200ALarge diameter, medium-low voltage and frequently dismantling, rapid installation.  Technical parameter:1. Medium available: mud, oil, water2. Medium temperature:0°C~90°C3. Ambient temperature:-30°C~50°C4. Medium presssure:0.6Mpa   TypeConnect Pipe O.D.Female Sub *Weld toMud Tank Union Dimensions in mmABCDEFGH4-inch4 ½"(114.3mm)6"26416815012750155114216-inch6 5/8"(168.3mm)8"34021920012750208168218-inch8 5/8"(219.1mm)10"343273253127502582192110-inch10 3/4" (273.1mm)12"432325305127503112732112-inch12 3/4"(323.9mm)14"491355336127503643242114-inch14" (355.6mm)16"557406.438112750.83953562116-inch*16"(406.4mm)18"////////18-inch*18"(457mm)20"////////20-inch*20"(508mm)22"////////Please don't hesitate to contact our sales if you are interested in any of our products.Sales AssistantAtt.: Mike LeeBETTER Drilling Fluid Equipment Industrial Limitedhttp://betterdrilling2008.en.made-in-china.com    /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
