Supercritical CO2 Fluid Extraction Equipment

Nature plants extract essential oil by SCFE-co2 system Description Introduction of supercritical CO2 extraction machine The super critical fluid extraction machine is specially suitable for extraction of fat-soluble andheat sensitive substances with high boiling point mainly consists of extraction kettle,separation kettle,fine distillation column,CO2 high pressure pump,entrainer pump,refrigerating system,heat exchange system,purifying system,pressure stabilizing system of extraction kettle,CO2 tank,flow meter,temperature and pressure control(protection)system etc.The supercritical CO2 extraction machine is specially suitable for extraction of fat-soluble and heat sensitive substances with high boiling point and widely used in pharmaceutical,foodstuff,cosmestyics & perfumery,chemical and other industies. Characteristics of supercritical CO2 extraction machine 1.The press ring of the extraction kettle can be opened quickly;O-ring is imported with service    period over 4 months. 2.CO2 can be used in circulation. 3.It can be designed and manufactured as per GMP standard. 4.The pressure stabilizing system of the extraction kettle is imported back-pressure valve. 5.It can be matched with computerized automatic sontrol system(temperature,prissure,flow). 6.All valaves of the device are under special heat treatment so they are robust and durable. Application scope of  supercritical CO2 extraction machine Application Scope Description Agriculture Food Extraction of pesticides and soil contaminants. Separation of fats and contaminants, flavors. Pharmaceutical Extraction of active components, preparation of natural products, vitamins. Cosmetic Extraction of fragrances and oils. Laundry Dry cleaning of garments. Mechanical Degreasing of parts, precision cleaning of high-value components. The principle and superiority of supercritical CO2 extraction machine Supercritical fluid extraction is a kind of green separation technology which separating solute from solid or liquid material by using supercritical fluid solvent. Supercritical CO2 fluid is a perfect solvent, first it has good permeabilityand low viscosity as gas, second it has close density and fine solution capacity as liquid, third solution capacity depend on the density, pressure and temperature of solvent. So the principle of SCFE is by changing the density, pressure and temperature of CO2 solvent to extract different solute from solid or liquid material. Material of Orange Peel Essential Oil Extraction FlowersRose; jasmine; lavender; chamomile; ylang ylang; geranium; neroli;clary sage;achillea millefolium; osmanthus; peony; marigold;l aurel; LeavesTea tree; eucalyptus; mint; patchouli; juniperberry; cypress; pine needles; spearmint; basil.RootsGinseng; ginger; angelica; garlic; vetivert; angelica root; mugwort; borneol camphor.GrassesRosemary; verbena; lemongrass; melissa; nardostachys; tarragon; caraway; dill; valerian; houttuynia; wintergreen;  evening primrose.WoodSandalwood; cedar wood; rosewood; agarwood; Birch; holly; camphor; melaleuca; sassafras.ResinsFrankincense; myrrh; benzoin; fir tree; amyris; Elemi.BarkCinnamon.CitrusBergamot; grapefruit; lemon; orange; lime; tangerine .SeedsCloves; almonds; cardamom; carrot seed; pomegranates; pepper; capsicum ; fennel.Jim Li     GENYOND MACHINERY INDUSTRIAL GROUP LIMITED ADD: RM709,NO.1328 Hengnan Road,Minhang District, Shanghai, China   Website: jouyumachine.en.made-in-china.com : /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
