H7005c-2rz-Dt-P4 Sealed Machine Tool Spindle Bearing Precision Bearing

Product Description   Bearing No. H7005C-2RZ DT P4-Angular contact ball bearing-spindle ball bearingTechnical DataInside Ø (mm):25Outside Ø (mm):47Width (mm):12Tolerance for inside-Ø (mm):0/-0,005Tolerance for outside-Ø (mm):0/-0,006Tolerance for width (mm):0/-0,12Tolerance for shaft da (mm):0,21/-0,21Contact Angle:15°Rows Of Balls:single rowSeal:rubber sealsRing Material:GCr15, 100Cr6, SUJ2Rolling Element Material:steelCage Material:Phenolic ResinTolerance Class:P4SLubrication:L252Type of lubrication:greasedProduct weight:0,074 kgFeaturesit is suitable for high radial and axial loads in one directionit has also an axial load carrying capacity on both sides in the X- or O-arrangement in pairsaccuracy grade: P4S (main dimensions at least according to ISO-tolerance class 4)all running tolerances are classified according to ISO-tolerance class 2it is designed for a high running accuracy and high speeds with maximum rigidity and operational safetyseal: open design (without seal)Exchange:B7005C-2RSD-P4S, 7005CTA/P4S (CSC), 7005CTRV1VDTP4 (NSK), 7008CD/P4AApplication: electric spindle , wood carving machine, engraving machine, CNC router, CNC machine,machine tool spindle bearingDimensionsTypeShaftDimensions in mmcontact angleWeight-Ø(kg)in mmDBcDadar(min)r1(min)ra(max)ra1(max) H7000C-2RZ-P4102686.422140.30.30.30.115°0.022H7001C-2RZ-P4122886.724.516.50.30.30.30.115°0.024H7002C-2RZ-P4153297.628190.30.20.30.115°0.028H7003C-2RZ-P41735108.532210.40.30.30.115°0.043H7004C-2RZ-P420421210.237250.60.30.60.315°0.067H7005C-2RZ-P425471210.842300.60.30.60.315°0.075H7006C-2RZ-P430551312.3493610.610.315°0.108H7007C-2RZ-P435621413.5564110.610.315°0.153H7008C-2RZ-P440681514.7624610.610.315°0.188H7009C-2RZ-P445751616695110.610.315°0.239H7010C-2RZ-P450801616.7745610.610.315°0.254H7011C-2RZ-P455901818.783621.10.610.615°0.377H7012C-2RZ-P460951819.488671.10.610.615°0.401Application  Company ProfileEstablished in 1995, as a leading ball bearing manufacturer in China, HXB offers more than 1,000 kinds of ball bearing to fulfill our customers' needs. With excellent production team and technical team, we can supply high quality products consistently. After more than 20 years of development, HXB's main products involves deep groove ball bearings, angular contact ball bearings, high precision spindle bearings, etc. Our bearings are wildly used in electric motors, machinery tool spindle, CNC, NEVs and other fields./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
