Non-Asbestos Filled Metal Jacketed Gasket

Metal Jacketed GasketsMetal Jacketed GasketsProduct Type:ZH2071,ZH2072Specification:ZH2071,ZH2072  Metal Jacketed GasketsMetal Jacketed Gasket is based on 0.2-0.6 mm thick soft metallic stripe which acts as the shell material, filled with non-nature fibre like graphite, asbestos or ceramics. It often needs some certain shape rods when used in heat exchanger. We can produce square, oval and other sort of shapes metal jacketed gasket. According to their shell material and filler material, the maximum operating pressure and temperature are normally from 6.0 to 10.0MPa and 1000 oC, respectively. The resilience for metal jacketed gasket is low which is mainly depended on the materials. But high quality flanges with good surface and preload capability are required. It is usually used for heat exchanger, pressure vessel and valve flange, and so on. Two types of metal jacketed gaskets, they areZH2071Metal Jacketed Gasket,ZH2072Corrugated Metal Jacketed Gasket. Metal shell Filler Domestic serial number Correspondingforeign serial number GraphiteSoft iron Soft IronAsbestosLow-carbon steel A3PTFE 0Cr18Ni9304Non-asbestos fibre00Cr19Ni10 304L Ceramic fibre0Cr17Ni12Mo2316 00Cr17Ni14Mo2316L 0Cr18Ni11Ti 321 1Cr13 410 CopperCopper  AluminunAluminun MonelMonel-400 TitaniumTitanium NickelNickel 200   Code No. Name ZH2071Metal Jacketed Gaskets ZH2072Corrugated Metal Jacketed Type  Gaskets  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
