High Frequency Metal 40kHz Ultrasonic Welding Equipment for Metal Welding

40Khz High Frequency Metal Ultrasonic Welding Equipment Σ1000M35Khz40KhzPower1000W800WPressure1000N1000NPower Input1000W/5AAC 220V +10% 50/60Hz800W/5AAC 220V +10% 50/60HzElectric Box Size420mm×211mm×185mm420mm×211mm×185mmElectric Box Weight10KG10KGMachine Size699mm×452mm×530.5mm699mm×452mm×530.5mmMachine Weight45KG45KG    Auto partsbumpers, air filters, car audios, foot pads, door panels, clutch forksElectric productshumidifiers, chargers, storage battery, telephones, sockets, flash discsMedical productsleucocyte filters, accurate liquid medicine filters, blood plasma separating cupsPackaging and clothingvalve bags, paper cups, dairy food packing cases, bag belts, zippersStationery and toyink boxes, file folders, name card holders, albums     The Ultrasonic Metal Welding Machine Σ1000M Series is a complete ultrasonic welding device that integrates ultrasonic digital generators and controllers with ultrasonic welding presses. The Σ1000M series has a variety of welding modes to meet customers' more stringent welding requirements.Ultrasonic welding machine with modes of time model and engry model, it can automatically track and display real-time frequency, with amplitude stepping function, welding amplitude range up to 10-100(1%accuracy). There is also amplitude compensation; welding quality management (time,energy mutual detection), including clear traceable welding records (operation statistics) to control your welding quality in real time. It also features transducer overload protection, mold impedance analysis and protection to protect your equipment. Powerful, high quality and high welding stability.Welded materials are placed above each other on a suitable support plate, that they touch at required welding place. On the ultrasonic generator could be set required parameters of joint as the welding time, output power or overall output. Welding device is activated by the manual switches or by footswitch. After the switch is switching, the pneumatic tool is pressed welding tool (sonotrode) to the top welding part. With intensive ultrasound from the welding tool come to meltingdown and after that to joint of plastic material where they touch. Weld time is determined by switching time switch or set the weld time using the timer control, whichever is less. After joint is complete, the sonotrode for the short time press welding materials together to achieve the required joint strength. Then the sonotrode will return to the resting position. Because of the large number of existing plastic materials and their shapes is neccessary tested suitability of usage ultrasonic welding tool for concrete aplication. When thinner materials is welded in addition to set duration of weld, may also be needed to reduce output power of ultrasonic generator. Advantages:*Full range of modular design*High-strength rigid structure*Digital ultrasonic generator*Maximum pressure 1000N  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
