305mm Ultrasonic Food Cutter Equipment Cutting Knife Machine

        305mm Ultrasonic Food Cutter Equipment Cutting knife Machine         Ultrasonic food cutting equipment use high-frequency vibration of 20,000 times per second generated by ultrasonic energy to create a surface with almost no friction between the blade and the food, thus eliminating problems such as sticking and squeezing.      The ultrasonic cutter is composed of a "transducer" that generates vibration and an "oscillator" that drives the transducer. A piezoelectric element is used for the transducer. When voltage is applied, the piezoelectric element displaces the transducer by a few micrometers. Periodically applying voltage generates vibration. Each object has its special frequency, by which the object is stable and easy to vibrate. By adding an external force that corresponds to that special frequency, a small force can obtain a large vibration. This phenomenon is called resonance. In the ultrasonic cutter, the piezoelectric element generates a force that resonates the whole body, from the transducer to the blade tip, generating a large vibration at the tip. The oscillator periodically generates voltage to resonate and drive the transducer. Using a component of the ultrasonic cutter called the horn to ring the cross-sectional area, from the piezoelectric element to the blade tip, can obtain a larger vibrationFrquency20kHzPower1000wInputAC110-240V, 50/60HzPower Controllerstepping or continuousLength of the blade305mmMaterial Of Cutting Headstainless steel, titanium alloy, alloy steelAccessoriesfoot switch, additional bladeCable Length3M or customized     Ultrasonic cutter is suit for cutting various frozen foods,viscous foods,suck like, cheese cake, nougat, wafer biscuits,  frozen cheese. The high frequency vibration of the ultrasonic can effectively reduce the cutting resistance, and make the cutting surface smooth and beautiful.        Also applied in rubber cutting , Rubber goods have high toughness, ultrasonic cutting knife can greatly reduceresistance and increase cutting speed.♦ Bakery and snack foods,♦ Candy and confectionery cheese/Fish/Prepared meat/Vegetable/Health Bars;♦ Chocolates, sandwich and wrap cutting;♦ Dry fruit;♦ Poultry;♦ Potted;♦ Processed meat;♦ Ground meat;FAQ   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
