Multi-Turn Bevel Gearbox for Gate Valve

ApplicationXBN series multi-turn spiral bevel gearboxes are used for manual or electric (with electric actuators) operation. It's suitable for gate valves, globe valves, sluice and sluice gate. Operating EnvironmentXBN series multi-turn spiral bevel gearboxes are with good mechanical quality and steady operating performance which apply to deal with variety climate and temperature. We strive to develop RB series spiral bevel gearbox to meet higher demands.Enclosure: IP67 (IP68, IP65 optional)Working Temperature: From-20ºC to 120ºC( -4ºF to 248ºF)Painting: Silver grey (Customization) IntroductionXBURS XBN multi-turn spiral bevel gearboxes series with spiral bevel gear used is in high quality and safety. Compared to conventional bevel gearbox it' s with high transmission efficiency, superior bearing capacity, low noise, steady running etc. RB series is completely sealed with good waterproof performance. It is easy to process axis hole and key groove because of the removable sleeve. RB series spiral bevel gearbox consists of both manual and electric operation, flange standard according to ISO 5210.Characters1. Totally enclosed gearing2. Grease filled for longer life3. Comprehensive gear ratios for differentapplications4. Removable output sleeve5. Optional output connection6. Manual and electric operation7. Sealed structure, protection to IP67 (IP 68 optional)Connect With ValveThe flange connecting to valve is according to ENISO5210 or DIN3210 (Customization) Main ProductsWorm gearbox, bevel gearbox, valve gear box,worm gear operator, worm gear actuator, valve worm gear, valve gear operator, valve gear actuator, valve actuator.Gear Operator, Valve Gearbox, Bevel Gearbox, Gearbox, Speed Reducer, Multi-Turn Bevel Gearbox, Bevel Gearbox Supplier, High Quality Bevel Gearbox, Gearbox manufacturer /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
