ASME Stamp and Stainless Steel Shell and Tube Tubular Heat Exchanger

Product descriptionThe fixed tube plate heat exchanger is to weld the tube sheets at both ends directly to the shell. It is mainly composed of main parts such as outer casing, tube sheet, tube bundle and head. A tube bundle is arranged in the casing, and the tube ends are fixed on the tube sheet by welding, expansion or expansion welding, and the outer circumference of the tube sheet and the head flange are fastened by bolts. The fixed tube plate heat exchanger has a simple structure and convenient pipe cleaning and maintenance. Product applicationWidely used in petroleum, gas, metallurgy, building materials, refractory, non-ferrous, chemical and other industries, as long as the use of heat sources and chemical heat exchange places can use heat exchangers Working Condition:1)Refrigerant side(In the tube): R22,R134a,R407c,R410a etc.2)Water side (Between the tube and shell):fresh water, nature water, drink water, seawater, saltwater, ground water etc .Material:1)Heat transfer Tube: 316L / SUS304 / Copper / Titanium2)Shell: 316L / SUS304 / Carbon steel / PP / PVCtube and shell heat exchanger,plastic heat exchanger tube,titanium shell and tube heat exchanger Specification for all heat pump SL: Sizetitanium tubewater inlet and outlettitanium tube working prssurePVC shell     working pressureeach VOL(CBM)1/3HP/1/2HPOD16*0.6mm*L3.3M     32mm3.0Mpa0.5Mpa0.0163/4HP/1HPOD16*0.6mm*L5.3M     40mm3.0Mpa0.5Mpa0.0281.5HP/2HPOD16*0.6mm*L9M         50mm3.0Mpa0.5Mpa0.0431HPOD12.7*0.6mm*L5M50mm3.5Mpa0.4Mpa0.0161.5HPOD12.7*0.6mm*L7.5M50mm3.5Mpa0.4Mpa0.0172HPOD12.7*0.6mm*L11M50mm3.5Mpa0.4Mpa0.0173HPOD12.7*0.6mm*L15.5M50mm3.5Mpa0.4Mpa0.0215HPOD19*0.6mm*L20M50mm3.5Mpa0.4Mpa0.08810HPOD19*0.6mm*L40M50mm3.5Mpa0.4Mpa0.09815HPOD19*1.0mm*L60M50mm3.5Mpa0.4Mpa0.19920HPOD19*1.0mm*L80M50mm3.5Mpa0.4Mpa0.18630HPOD19*0.55mm*L120M50mm3.5Mpa0.4Mpa0.271 Remark:1HP=3.5KW    1Mpa=10bar     refrigerant:R22 /R134/R407/R41OA .  Titanium tube: Product detailinside: titanium coiltitanium tube materialseamless tube--TA1titanium tube diameter12.7mm----30mm(normal use)titanium tube thickness0.55mm----3.0mm(normal use)outside: PVC casePVC cover materialenviromental protectionPVC tube diameterOD110mm----OD400mmPVC tube thickness2.7mm----15.3mmconnectiongas inlet and outlettitanium thread and copper nut/tubewater inlet and outletplastic pistontesting/otherswater pressure0.25----1.0Mpa(2.5---10bar)gas pressure3.5MpaPVC temperature≤45°Cshell leakagenotube leakagenopack0.6mm thick gray spongecorrosive or notanti-corrosionusepool /heat pump/ air conditioner/chillar etcSpecifications of heat exchanger:1. Heat exchanging quantity:___ (KW,KCAL)2. Hot side media: 3. Hot side inlet temperature: 4. Hot side outlet temperature: 5. Hot side flow rate: 6. Cool side media: 7. Cool side inlet temperature: 8. Cool side outlet temperature: 9. Cool side flow rate: Please fill in at least five of above specifications, so that we can design the heat exchanger accurately.   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
