Air Cooling Chiller with Heat Recovery

Industrial Air Cooled Water Chiller Shenglin is a professional manufacturer  in China specializes in refrigeration units and air conditioning units..Air cooled chiller Features1. Compressor: Vortex type compressor, adopt international brand fully enclosed vortex type maintenance free compressor2. Heat exchanger: 5HP or bigger model, use high efficiency shell and tube evaporator and condenser 3. Control system: our own cotrol system, simple operation, accurate control;4. Man-machine interface: the use of well-known brand controller and control interface, digital display, one key operation5. Water tank: adopt the overall design and manufacture, the built-in standard high efficiency centrifugal pipeline pump, 304 stainless steel storage tank6. In order to adapt to the different requirements of all walks of life, the use of different series of scroll compressor, refrigeration water temperature from 15 degrees to -35 degrees, sophisticated technology to ensure the stability of the work under the extreme conditions7. The choice of environmental protection type R407C or R134a refrigerant. Air-cooled chiller parameters(output temp 7ºC)ModelUNITSLPA-20.225.230.240.2Cooling capacityBtu197896223145280466377367RT16.518.623.431.5Kw58.065.482.2110.6×10³Kcal/h49.956.370.795.2Total PowerKW18.420.528.638.0Total CurrentA33.637.652.369.5CompressorQtyset2.002.002.002.00Input powerKW15.717.924.933.3Operation CurrentA28.031.844.359.2 Condenser FansTypeEfficiency copper and Blue hydrophilic aluminum Finned heat exchangerInput powerkw1.141.141.502.52InputCurrentA3.003.003.845.10"EvaporatorTypeHorizontal shell-and-tube/Coil type high efficiency copper heat exchangerChilled water FlowL/min166187235316Water pipe connectionmm40505065" Chilled Water PumpTypeHigh efficiency, low noiseInput PowerKw1.501.502.202.20Headm24232221RefrigerantTypeR22Water tank Indicating VolumeLiter270320360400Safety protectionhigh and low pressure protection, overload protection, over temperature protection, phase sequence protection, etc.Dimensions (L*W*H)Lengthmm1950210022002450Widthmm1250125012501350Highmm1600160018502050Total WeightKG830105012501350  Note:1, the table refrigeration conditions: cold water inlet temperature 12 ºC, cold water outlet temperature 7 ºC, ambient temperature 35 ºC, the use of ambient temperature range -7 ºC ~ 43 ºC;2, crew safe operating range: Chilled water inlet temperature 9 ~ 20 ºC;3, the series unit uses imported from Europe hermetic compressors, superior performance, strong anti-strike capability liquid;4, standard power supply: 380V / 3N-50HZ, voltage fluctuation allowed ± 10%, frequency fluctuation ± 2%;5, host the actual head of the pump head minus head losses within the host. (1mH2O = 9.8KPa)6, In addition to the specifications and requirements, we can provide non-standard products according to customer requirements.      /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
