Fin Welded Tube Heat Exchanger

Fin Welded Tube Heat Exchanger  Product DescriptionThis air cooling coils is made of copper tube with copper sheet (or aluminum fin) ,enjoy advanced mechanical tube expander and double-flange aluminum fin structures.Standard Component Materials:Tube:Copper tube,Stainles Steel tube. Fin:Copper sheet ,Aluminum Sheet. Casing: Galvanized sheet, Carbon Steel,Stainless Steel. Header:Iron,Copper tube,Stainless Steel.FeaturesAir Cooling Coils Advantages:1,Hihgly heat transfer coefficient .The copper tube expander makes copper tube contact the aluminum sheet and accelerate the turbulent flow,destroy the boundary layer ,and enhance the heat transfer coefficient .2,Excellent heat transfer performance.This structure ,together with the rationally designed water route,tube distance and sheet distance offer excellent heat transfer performance,small air resistance,compact structure,light weight and other advantages.Product ParametersAir Cooling Coils Size: Copper tube ODHole PitchRow PitchFin MaterialFin Pitch9.52mm25.4mm22mmAluminum Sheet/Hydrophilic Aluminum Foil/Copper Sheet/Epoxy Aluminum Foil8PFI~14PFI12.7mm31.75mm27.5mmAluminum Sheet/Hydrophilic Aluminum Foil/Copper Sheet/Epoxy Aluminum Foil8PFI~14PFI12.7mm48mm41.57mmAluminum Sheet/Hydrophilic Aluminum Foil/Copper Sheet/Epoxy Aluminum Foil3PFI~6PFI15.88mm38.1mm33mmAluminum Sheet/Hydrophilic Aluminum Foil/Copper Sheet/Epoxy Aluminum Foil8PFI~14PFICompany Profile      /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
