Jumbo Ton Bulk Bag Unloading Machine Station System

Product DescriptionThe ton bag unloading and feeding station consists of a frame with a unloading hopper, an electric hoist, a diaphragm valve, a pneumatic massage device, a dust removal device, etc. Lift the ton bag from the ground to the equipment inlet through a crane/forklift, manually open the diaphragm valve, drop the ton bag inlet into the silo inlet, and then close the diaphragm valve. After opening the ton bag discharge port at the side quick opening bag opening, discharge begins; This equipment is supplemented by pneumatic massage boards and vibration devices to facilitate the complete discharge of materials from the ton bag.  Specification of ton package1000 × 1000 × 1200Operating environment-15 °~50 °Operating pressurenormal pressureAir source pressure0.4~0.6MPaApplicable materialspowder, and particle materials with good flowability and average flowabilityMoisture content≤ 3%Product structure:Main structure: unloading station frame support structure, ton bag lifting device, ton bag hanger, ton bag support massage board, bag mouth control valve, sealing device.Material hopper: it can be combined with the Glovebox design to effectively isolate dust and gas from the operator; You can choose a fluidizer and install a breaker under the hopper, or weigh the hopper to achieve metering function.Discharging equipment: rotary valve+gravity feeding, screw conveyor, vibration conveyor, pipe chain conveyor, rotary valve+airflow conveying, negative pressure conveying, etc.Lifting equipment: The self carried lifting equipment is used to lift the large bag (ton bag) onto the frame of the unloading machine, without the need for external assistance.Product Features1. Dual use of ton and small bags, with simple structure and easy operation,;2. The tapping equipment can ensure the smooth entry of materials from the large bag into the next process;3. Automated operation to improve production efficiency and reduce labor intensity;4. Closed feeding, preventing dust from flying and generating no heat, improving the working environment, and reducing production costs;5. The integrated design of bag opening, tapping, and material placement features a compact structure and convenient operation.Appliction IndustriesSuitable for automatic unpacking and unloading of dry powder and granular materials in fields such as food, medicine, chemical, metallurgy, and new materials, such as nitrate lime, magnesium oxide, quartz sand, limestone, sawdust, activated carbon, PVC powder, fly ash, etc.Customer Reference  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
