Product OverviewAccurate feeding Screw conveyorSPL type Micro-Feed Screws are auxiliary screws combined with a larger main screw feeder. Before reaching the set feed rate the main screw feeder is stopped by a proximity switch to allow the Micro-Feed Screw, which is flanged beneath an opening in the pre-outlet section of the main screw feeder pipe, to feed the missing quantity of material with high accuracy through the outlet of the main screw feederinto the weigh hopper.FEATURES AT A GLANCEDiameter :168 ~558mm.Capacity: 43~1100dm3/min.Application:Building materials, chemical industry, electric power, metallurgy, coal charcoal, grain ,coal, ash, slag, cement and grain.Etc.Customized Solution is the Core concepts of SDCADProduct Type:Horizontal Screw Conveyor,Inclined Screw Conveyor,Vertical Screw Conveyor, Shaftless Screw Conveyor       Horizontal Screw Conveyor                               Inclined Screw Conveyor                     Shaftless Screw Conveyor        PRODUCT SPECIFICATIONS Type Metering screw Ø (mm) Main Screw Ø (mm) KW Hopper volume (dm3) Metering time (sec) Q (dm3/min) SPL0901681 90 168 0.55 22 8 43 SPL0901931 90 193 0.55 24 7 86 SPL1002191 100 219 0.55 56 9 117 SPL1002731 100 273 0.55 62 10 117 SPL1203231 120 323 1.1 80 9 220 SPL1504061 150 406 1.1 121 10 430 SPL1504571 150 457 1.5 171 15 430 SPL2005581 200 558 3 355 10 1100 Our product Advantages1.Ideal for conveying dry to semi-fluid bulk materials - free flowing to sluggish;2.Cost-effective when compared to other conveying devices such as belt, pneumatic or aeromechanical;3.Efficiently distributes bulk materials to various locations using multiple inlet and discharge points;4.Totally enclosed for dusty, corrosive or hazardous environments;5. The structure is simple, compact, low cost in production, easy maintenance and low in cost;6.Because it is made of seamless pipe, the sealing effect is good, so it is suitable for easy flying, hot materials, toxic and odorous materials;7. It has stirring, mixing and cooling operationsDiameterCapacity0 degree45 degreesmaterialSS114MM6.5T/h6T/h SS168MM25T/h20T/hCarbon Steel/Stainless steelSS219MM70T/h55T/hSS273MM100T/h75T/hSS323MM125T/h95T/hSS406MM160T/h120T/hAll dates is based on cement with stacking density 1.13 t/h   PRODUCT CONFIGURATIONDifferent styles of screw conveyor customaziedTo choose the suitable model, please tell us*Name and feature of the raw material?* Conveying lengths?* Handling capacity: kg /h, L/h?* The Inclined angle you want?Build Solutions for you*Design the equipment according to your request.*Providing solutions according to the real situation.*Relevant technical documents would be available.*Delivery on time.Warranty: 18 months            Tube Screw Conveyor                                       U Screw Conveyor                             Without-Shaft Screw Conveyor        Multi-Shaft Screw Conveyor                         Screw Conveyor with Hopper                        Vertical Screw Conveyor      Customized Screw Conveyor                          Precise metering spiral                            Stainless Steel Screw Conveyor  Product ShowApplicationPackaging and TransportationOur Service Pre-Sales ServiceCustomer consultant 24 hour online;Engineer team provide design drawing;Skilled staff responsible for production;Take pictures for all Production process.  After-Sales ServiceProvide installation instruction;Solve any problems involved; Tell the machinery maintain guidance;Regular monthly sales tracking.Related Products                Bolted Silo                               Container Horizontal Silo                            Big Bag HopperSALES AND SERVICE NETWORKFAQMay you introduce your Factory?Our factory is with 10,000m2 factory floor area. More than 100 workers will service for you. Our factory is located in Shandong -the only province which cover all industrial sectors in China. What's the Advantage of your products? Full Process Solution Provider of Mixing, Storage, Conveying.Our engineers team provide Customized Solution for every project!What is your Delivery time? 3-7 days for spare parts; 10-20 days for simple machine. 30-50 days for production line.What Certificate do you have to ensure quality? CE certification is provided.ISO health, ISO Quality, ISO Environment are provided.Do you have Quality Check QC Service? QC checking work is including from material, steel processing, welding, painting, electric system, test, delivery, installation.Quality check for full processHow can I Get Solution to my inquiry?Pls send inquiry to us now,More project and contact information more better. Engineers will make plan for you. Our Sales manager will Quote to you in the first time./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
