Mbr Membrane Module Reinforced PVDF Slmbr-25 Waste Water Treatment

Product DescriptionMBR is a combination of membrane technology and bio-chemical  reaction  in water treatment. MBR filter the sewage in bio-chemical tank with membrane so that sludge and water are separated. On one hand, membrane rejects microorganisms in the tank, which greatly increase the concentration of activated sludge to a high level, thus the bio-chemical reaction of sewage degradation processes more rapidly and thoroughly. On the other hand, water output is clear and of high quality because of high precision of membrane.This product adopts reinforced modified PVDF material, which will not peel or break  during  backwashing,  meanwhile  it  has  good  permeable  rate,  mechanical performance,  chemical  resistance  and  anti-fouling  ability.  ID  &  OD  of  reinforced hollow fiber membrane are 1.0mm and 2.2mm respectively, filtering precision is 0.1 micron.  Filtering  direction  is  outside-in,  that  is  raw  water,  driven  by  differential pressure, permeates into the hollow fibers, while bacteria, colloids, suspended solids and microorganisms etc. are rejected in the membrane tank. Product Parameters SLMBR-25 technical detailsModel SLMBR-25Filtering directionOutside-inMembrane materialReinforced modified PVDFNominal membrane area25m2Filament diameter  ID1.0mm,OD 2.2mm Out size785mm×2000mm×40mmConnection sizeDN32  Component Material:ComponentMaterialHollow Fiber MembraneReinforced Modified PVDFSealing CompoundEpoxy Resins + Polyurethane (PU)HousingABS  Using ConditionsProper   pretreatments   must   be   set   when   raw   water   contains   a   lot   of impurities/coarse particles or large proportion of grease. Defoamer must be used to remove foams  in  membrane tank when  necessary,  please  use alcoholic defoamer which is not easy to scale.ItemLimitRemarkPH Range5-9 (2-12 when washing)Neutral PH is better for bacterial cultureParticle Diameter95%★ High strength:>2000CN★ Long service life: Use imported PVDF raw material, which has              goodchemical resistance, good hydrophilicity, anti-agingability,              long service life.  Application★ Municipal sewage upgrade ★ Integrated water treatment equipment ★ Industrial wastewater upgrade ★ Refuse leachate treatment Detailed Photos   Plant photo Packaging & ShippingCustomer site Certification and test report FAQ---Replace the filter cartridge step1. Receive the production instruction to replace the cartridge and confirm that the system has stopped running.2. Prepare the appropriate filter element (specification, material, size, O-ring material, type, etc.), disassembly tools, collection bucket, rags, etc.; and3. Thoroughly clean the filter housing, empty around the filter, and leave the operation area. Take protective gears with you.4. Disconnect the filter to be replaced from the system. Slowly open the exhaust port at the top of the filter and depressurise it, paying attention to safety in the process to prevent material or liquid from splashing.5. Empty the material in the filter, open the filter cover with a tool, take out the filter cartridge, and pack the cartridge in a plastic bag to be scrapped; 6 Use clean tools and rags to clean the filter.6. Use clean tools and rags to clean the inside of the filter and install the new cartridge.7. Open the plastic bag at the open end of the filter element and check whether the O-ring is intact and in place.8. Install the inflow of materials according to the method of inflow from the outside of the filter element and outflow from the inside of the filter element.9. with the appropriate wetting agent (such as water) wet O-ring and cartridge seat jack, hand-hold the cartridge near the end of the O-ring, vertically insert the cartridge cartridge socket completely into the cartridge seat jack, the cartridge inserted, remove the cartridge bag, and then install the metal cover, with tools to tighten the filter; 10 close the filter drain port, open the plastic bag, open the filter, the filter is complete, in place.10. Close the liquid discharge port of the filter, open the bleeder valve at the top of the housing, slightly open the inlet valve, so that the material enters the housing until the liquid overflows from the bleeder valve at the top of the housing, at this time close the bleeder valve. Pay attention to check the disassembly place, whether there is leakage;.11. Slowly open the filter outlet valve until it is completely open. Indicates that the replacement is complete.12. Remove the tools used for replacement and cleaning tools. Clean up the surrounding area.---Bag filter instalation step 1. First of all, it is necessary to confirm whether the accessories required for the installation of bag filter have been prepared;2. Check the O-ring seal and the O-ring groove on the bag filter in order to replace the accessories in time;3. When installing the bag filter, it is necessary to place the bag filter on the work station that needs to be filtered. After connecting the inlet and outlet flanges
