High Current Smart Mains Distribution Unit Mdu

High Current Smart Mains Distribution Unit Mdu  A smart mains distribution unit smart MDU is a power distribution unit with internet networking capabilities used to remotely read power data and turn outlets on and off. Advanced smart mains distribution unit also include adjustable set points which constantly monitor power data, and send alerts to users and other networked systems when there are excessively high or low values. Smart mains distribution unit is also known as intelligent PDU or networked PDU,Smart PDUWe Provide Customized Smart Mains Distribution Unit According To You Needs.We Are Professional Manufacturer Since 1996, Providing Customized And OEM ,One Station Solution.Technical Parameters: Dimensions: 277L*249W*68H mmWorking voltage: DC9V~DC36VWorking temperature: -40ºC~80ºCStorage temperature: -40ºC~80ºCAnti-seismic performance :Meets 10~500Hz (three-way 3g/8h) test standardSalt spray resistance: 48-hour salt spray test standardVoltage interference :Meets C-1 forward 110V, C-2 forward 170V, D reverse 320V test standardsProtection grade:  IP66Shell material:  ADC12 aluminum alloyModule weight :2.16KGReverse connection protection:  YesCommunication interface: up to 2 channels HS-CAN, 1 channel CANFDPower connection: one channel 200A power supply + DC-DC input, one channel 80A dual source power steeringIO resources: 10 channels inputs, 27 channels inputs, 3 channels outputs 50A, 5 channels outputs 30A, 4 channels outputs 15A, 14 channels outputs 10AFeatures:  1. All aluminum CAN bus controller, in line with CAN2.0B standard, protection grade up to IP66 2. Professional automotive-grade components, imported high-power chips, stronger control ability, higher reliability and longer life 3. Can directly drive high-power components such as motors and lamps without relay transition 4. Programmable setting of control logic and protection current for all channels, real-time monitoring of the load status of all access channels 5. With output over-current protection, short circuit protection and other functions 6. Adopt German BOSCH and VDO company design standards, follow the "fault-oriented safety" design concept, technically guarantee that even if there is a failure, the line safety can be guaranteedInstallation Notes: 1. When designing the installation location of the power distribution box, please install it as close to the battery as possible to reduce the length of the harness2. The power distribution box is fixed to the side wall of the electric cabin through the four fixing holes on the periphery, and is fixed by M6 steel bolts, plus flat pads and spring pads, and the torque is 15NM3. Please purchase the plug-in corresponding to the harness end of the power distribution box from regular manufacturers to avoid assembly difficulties caused by counterfeiting errors  Product NameSmart Mains Distribution UnitMOQ1SetSupply Ability1000 sets/monthPackingStandard Exprot Carton  Hot Selling Products Jining Zhineng Construction Machinery Co., Ltd. was established in 1996 and have developed to be a professional manufacturer and providing customized and OEM products. We are a high-tech. enterprise in China, our company is certified according to ISO 9001:2015.We providing mini excavator, forklift, anticorrosion tape, waterproof tape, instrument cluster assembly, cabin assembly, steering column assembly, seat assembly, wiring harness assembly and other spare parts for variety of construction machinery, mining machinery, agricultural machinery, special vehicle machinery. You can choose in combination or individually according to your needs.In our company 60% of employees are R&D personnel. Hence, we have good ability to research and develop new technologies and products which help us to be one of the leaders in China markets. We can design and develop the products with advanced technical performance as per the clients' requirements, and suitable for various construction machinery, mining machinery, agricultural machinery, special vehicle machinery.We have cabin assembly workshop, steering column assembly workshop,seat assembly workshop, wire harness assembly workshop,instrument cluster assembly workshop,sheet metal processing workshop,spray paint and power coating workshop.Zhineng products have achieved high reputation in construction machinery industry at home and aboard, which are regarded as "the leader in China "by universal customers. Our partners have Shantui, Liugong, Zoomlion,Yishan, Junlian, CRCC etc and have been distributed into more than 30 countries and regions such as Korean, Indonesia, Malaysia, Philippines, Singapore, Vietnam, Thailand, India, Pakistan, Qatar, Oman, Kuwait, Kazakhstan, Turkey etc.Our orientation: Strive to provide high-quality products and contribute to increase satisfaction for our clients through our advanced technique, perfect process, reasonable prices and considerate service.  Packing and ShippingFAQ 1. Are you original manufacturer?   Zhineng construction machinery is profess
