Right Angle Pitch 2.54mm DIP Switch

2 to 12 Position Slide Type Right angle pitch 2.54mm DIP Switch Connector  FEATURES2.54mm Pitch2P  to  12PSPSTRaised Actuator Through HoleRed or Blue or Black colorSPECIFICATIONSRating:DescriptionSwitching: 25mA 24VDC  Non-Switching:100mA,50VDCContact Resistance: initial50mΩ maxafter life test100mΩ maxInsulation Resistanct100MΩ min at 500VDCWithstand Voltage500VDC for 1 minOperation Force1000g maxSwitch Travle2.0mmMechanical Life2000 CyclesOperating temperature -40ºC~+85ºCStorage temperature -40ºC~+85ºC SOLDERABILITYManual Soldering30W iron,320±5ºC,3S maxWave   Soldering250±10ºC,5S maxNote:keep in "off" position during solderingEnvironmentWe hereby confirm that all the raw materials in our product including components, parts, materials and finished products are fully conform to:1. The EU's RoHS 2.0(Directive 2011/65/EU & EU 2015/863 )2. SVHC(Substance of Very High Concern) of EU directive of the Regulation(EC) No.1907/2006(REACH).ITEMSMOQ:100PCSLead time:about 5-10 daysExport port:ningbo or shanghai portShippment terms:by sea or by air or by expressSamples is free,freight collectBest price with high qualityDRAWINGPRODUCT PICTURESAPPLICATION:MAIN CUSTOMER:FACTORY VIEW:   SHIPPING & PAYMENT--------------------------------------------------------------------  1. FedEx/DHL/TNT/UPS/EMS/SF for samples, Door-to- Door.2. By Air or by Sea for Mass production.    Customers specifying freight forwarders or negotiable shipping methods.                            3. Delivery Time: 3-7 days for samples; 10-30 days for Mass production.  4. Payment Detail: L/C, T/T, Western union, Paypal, or other methods./* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
