8 HD Encoder H. 264 to Ethernet, IPTV HD Sdi Encoder

The encoder is a professional HD audio & video encoding and multiplexing device with powerful functionality. It has 8 channel HD input interfaces, supporting MPEG4AVC/H.264 High Profile code format. This device can simultaneously encode 8 channel HD programs; moreover, it has an ASI input and can multiplex the input TS with the 8 encoded SPTS to generate a MPTS output. Also, the PSI/SI information can be inserted into MPTS output. In conclusion, its high integrated and cost effective design makes the device widely used in varieties of digital distribution systems such as CATV digital head-end, satellite and terrestrial digital TV, etc.  Supports MPEG-2 video encoding, and advanced video pre-treatment The audio formats are MPEG-1 Layer2, LC-AAC and AC3. 8(4) CVBS video input 8(4) pairs of unbalance stereo audio input Multiplexes one ASI input Supports PAL,NTSC SD signal Supports IP output Supports MPTS or 8(4)xSPTS output over UDP Keyboard and LCD operation Support SNMP or web management   Input8 CVBS inputs , BNC interfaceSFT3208A8 pairs unbalanced stereo audio input, BNC interface4 CVBS inputs , BNC interfaceSFT3204A4pairs unbalanced stereo audio input, BNC interface1 ASI stream input, BNC interfaceVideoResolution720×480_59.94i, 544×480_59.94i,352×240_59.94i320×240_59.94i ,176×240_59.94i,160×120_59.94i720×576_50i ,640×576_50i,352×288_50i320×288_50i, 176×288_50i, ,176×144_50iEncodingMPEG-2Bit-rate0.8Mbps~19Mbps each channelRate ControlCBR/VBRGOP StructureIPPPP, IBPBP, IBBPB, IBBBPAdvanced PretreatmentDe-interlacing, noise reduction, sharpeningAudioEncodingMPEG-1 Layer 2,LC-AAC and AC3Sampling rate48KHzResolution24-bitBit-rate32Kbps~384Kbps each channelMultiplexing1 ASI input multiplexed with local 8(4) channels TSStream output2-way ASI output, BNC interfaceMPTS or 8xSPTS over UDP,10/100Base-T Ethernet interfaceSFT3208AMPTS or 4xSPTS over UDP,10/100Base-T Ethernet interfaceSFT3204ASystem functionLCD/keyboard, network management(SNMP/WEB)Chinese and English languageEthernet software upgradeMiscellaneousDimension(W×L×H)482mm×410mm×44mmApprox weight 2.8kgEnvironment0~45°C(work);-20~80°C(Storage)PowerAC 100~240V±10%,50/60Hz  The SOFTEL SFT3204A 4 in1 (SFT3208A 8 in1) MPEG-2 Super Encoder (with IP output) is a professional audio&video encoding and multiplexing device. This device has  4 (8) CVBS input interfaces and  4 (8) pairs of unbalanced analogue stereo audio input interfaces, and two ASI output interfaces which can output the multiplexing and condensed data. Moreover, this device can simultaneously encode  4 (8)channel audio& video signal and can multiplexer one ASI input stream to MPTS. Besides, it supports the criterion MPEG-2 encoding format, and the audio encoding formats supports MPEG1 Layer2, LC-AAC and AC3. Furthermore, this super encoder has the IP output function; users can manage the device according to the SNMP/Web. In conclusion, its high compatibility and integrate design make this device widely used in a variety of digital TV broadcasting systems. /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
