Aluminum Sheath Insulation and Sheathing Extruder for Granule

Aluminum Material Extrusion unit 1.Description:Suitable for continuous extrusion production of aluminum round wire, aluminum strap wire, aluminum bar and profile, etc.Extruded products are soft, using wire reel winding, also can be equipped with a wire cutting saw.The extruding belt is lengthened, fully extruded and the product organization structure is uniform.Using special heat treatment technology, the life of the extrusion wheel is significantly improved compared with similar products.2.Equipment Pictures3.Technical ParametersNoNameRLB285(300)/110RLB315/132RLB350/200RLB400/2501Extrusion FormSingle-wheel single-groove lateral extrusion2Range Of ApplicationRound aluminum tube, porous aluminum flat tube, aluminum strap wire, aluminum conductor, aluminum bar (profile), etcAluminum bar3Nominal Diameter Of Extrusion Wheel∅285∅315∅340∅4004Main Motor Power Of Extruder110KW132KW200KW250KW5Rated Speed Of Main Machine16r/min18r/min20r/min20r/min6Max. Production Speed14m/min16m/min20m/min25M/min7Product Diameter∅20mm∅25mm∅30mm∅60mm8OutputAluminium tube: 150kg/hAluminium tube: 180kg/hAluminium tube: 360kg/h450kg/h9Leak Amount≤5%≤5%≤5%≤5%10Raw Material: Oxygen-Free Copper Rod∅9.5mm Aluminum rod: ∅9.5mm2×∅9.5mm Aluminum rod: 2×∅9.5mm∅15mmAluminum rod: ∅15mm∅15mmAluminum rod: ∅15mm4.Layout:5.Application Demonstration:Extruded products are soft, using wire reel winding, also can be euqipped with a wire cutting saw.Product improves product hardness by drawing, and it is equipped with wire cutting saw length cutting at the same time, automatic material reck to arrange and shape products for easy packaging.Irregular conductor can be extrudedHigh quality aluminum tube can be extruded  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
