Electric Aluminum Clad Conductor for ACSR/AAC/AAAC/Gsw/Acar

Product Name:ALUMINUM CONDUCTOR COMPOSITE CORE1,Definition: Is a high capacity, low slag conductor which consists of a carbon fiber composite core encased in a protective fiberglass sheath that is helically wrapped with high purity conductive aluminum strands.2,Application:It is a new type of overhead transmission line conductor, its outstanding characteristics are light weight, tensile resistance, good thermal stability, small relaxation, strong flow capacity per unit area and corrosion resistance. Especially suitable for the company's resident coastal, mining areas with high corrosion intensity, pollution intensity, easy to run wire operating environment.3,Standard:GB/T 32502-2016; Q/320282 DFP08-2017; Q/320282 DFP05-2017;4, Packing:Wooden steel wood drum or Steel drum5,Technical Parameter:ACCCCond.Dia.Core Dia.WeightCore Related StrengthCond. Rated StrengthACCCCond.Dia.International Sizes(kcmil)(mm2)(mm)(mm)(kg/km)(kN)(ohm/km)180°C200°CCopenhagen434219.918.295.9766160.40.20941,0171,070Lisbon623315.521.797.1194885.70.14601,2841,353Brussels832421.425.158.131265112.00.10971,5491,632Hamburg1078546.428.638.761627130.20.08461,8341,935Milan1120567.729.118.761686130.20.08131,8801,984Rome1169592.529.909.531774153.80.07801,9352,043Vienna1242629.230.438.761853130.20.07332,0072,119Munich1447733.132.849.532170153.80.06322,2112,336London1498759.033.409.782248162.10.06092,2642,392Paris1606813.734.168.762366130.20.05682,3582,492Berlin (Madrid-lce)19861006.538.2010.542949188.30.04582,7132,872Madrid19991013.038.209.782948162.10.04542,7212,880Athens27821409.644.7510.544066188.30.03283,3353,538Ampacity values based on 50 Hz, zero elevation, 90° sun altitude, 25 °C ambient temperature, 0.5 Solar Absorbtivity, 0.5 Emissivity, 0.61 m/sec wind and 96 1,033 W/m2, atcorresponding surface temperatures. Coefficient of thermal resistance is 0.00403 for international sizes.6,Product Type:TypeShapeDia. of coremmArea of Almm2Rate break loadingKNUnit weightKg/km20°C DCΩ/kmLine expansionFactor X10-6 1/ºCUnder turning pointAbove turning pointThe formed annealed aluminum conductors composite core supported95/30~800/95 6.00~11.0095~80064.85~245.7318.5~2406.50.2939~0.035115.1~18.91.8Thermal-resistant Aluminum-alloy Conductors Composite Core Reinforced150/35~630/70 6.50~9.50182.0~710.876.97~213.4477.40~1907.450.1972~0.045916.5~19.21.8Formed Intermediate Aluminum Conductors Composite Core Supported95/30~1660/95 6.00~11.0095~166069.30~373.0317.19~4811.70.0173~0.297115.2~20.81.8 150/35~630/70 6.50~9.50182.00~710.8083.94~228.27477.40~1907.450.0459~0.197216.5~19.21.8The High-elongation Hard Aluminum ConductorsComposite Core Reinforced150/30~630/70 6.00~9.50154.2~639.973.7~221.5482.0~1910.2≤0.187117.3~19.21.8The High-conductivity (62.5% IACS) Aluminum ConductorsComposite Core Reinforced150/30~630/70 6.00~9.50154.2~639.972.1~213.6479.1~1903.8≤0.184117.3~19.21.8  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
