U1000 R02V Copper Cable 3G1.5

STANDARDS IEC 60502 NFC    APPLICATION U-1000 R2V cables can be used in all low voltage power installations. Multiconductors cables are adapted to remote control and telecontrol installations. In case of high ambiant temperature, use correction coefficient.   INSTALLATION These cables can be fixed on cable trays, within conduits or fixed to walls. They also can be buried directly with extra mechanical protection. Cross sections 1,5 - 2,5 and 4 mm² have to be of class 2 flexiblility, if the cable is connected to equipment subject to vibration.     CONSTRUCTION  Conductor material Bare copper  Insulation XLPE (chemical)  Outer sheath PVC  Sheath colour Black   ELECTRICAL  Rated Voltage Uo/U (Um) 0.6/1 kV  MECHANICAL Mechanical resistance to impactsGood  Cable flexibility Rigid USAGE Max. conductor temperature in service 85°C Short-circuit max. conductor temperature 250°C Operating temperature, range-10 .. 60°C Weather resistance Very good Flame retardant C2, NF C 32-070 Chemical resistance Accidental Bending factor when laying 6(xD)   /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
