Overhead Underground Heavy Duty Electric Silicone Rubber Sheath High Temperture Resistant Cable

Overhead Underground Heavy Duty Electric Silicone Rubber Sheath High Temperture Resistant CableStandard :IEC60245 / VED 0282Construction :    1.Conductor: Annealed flexible copper conductor (class5)                            or Tinned Copper conductor(Class5) for Flat Rubber    2.Insulation:EPR Rubber(Ethylence-propylene)    3.Insulation Color: 2core :Blue/Brown(Flat Rubber)                                  3core :Blue/Brown/Yellow&Green                                  4core :Blue/Brown/Yellow&Green/Grey                                  5core :Blue/Brown/Yellow&Green/Grey/Black     4.Sheath:EPR Rubber(Ethylene-Propylene                    CR Rubber(Poly-chloroprene) for Flat Rubber     5.Sheath Color:Customized  Characteristic:1.Temperature Rating: -30ºC  up to  70ºC  2.Voltage Rating:300/500V  3.Testing Voltage:2000V4.Min inner bending radius: 7x overall diameter                                            4x overall diameter for Flat Rubber5.Behaviour in fire: Flame retardant to IEC60332-1                                                                                                                                                                         Application:   Light rubber cable H05RR-F is used for easy-duty and medium mechanical loads in dry areas.Suitable for household,kitchens,offices and workshops for smaller electrical devices(washing,vacuum-cleaners,irons,household appliances,soldering sets) and mobile devices operating in heavier conditions,such as light industrial and agricultural machines. Not suitable for permanent outdoor use. Ozone-resistant,allowed contact with oils.greases. Flat rubber cable H05RNH2-F is used for decorative lighting. Suitable for in dry,damp or wet areas,indoor & outdoor, as the insulated conductor for lighting fixtures on squares,in garden.Technical Parameters:No.of cores x Nominal section areaNominal Construction of conductorNominalInsulationthicknessNominalSheath thicknessNominalOverall diameterNominalCable weightMax.Resistance of conductorat 20ºCNo.X mm²No.X mmmmmmmmkg/km
