PLC SC/APC Connector 1X8 Rack Mount PLC SplitterFiber Optic PLC Splitter DescriptionOptical coupler is an optical device that combines or splits power from optical fibers. Optical splitter divides light from a single fiber into two or more fiber channels. Fiber Optic PLC Splitter FeaturesVarious coupling ratio Single mode and multi mode available Low insertion loss, low PDL Environmental stable Industry standard and custom housing available Variety of connectors available 1x2, 1x4 and 1x n customized couplers configuration available Fiber Optic PLC Splitter ApplicationsOptical communication system System and signal monitoring CATV Systems & Fiber Sensors Fiber to the home (FTTH) Network redundancy Laser splitting Fiber Optic PLC Splitter PerformancePorts1x22x21x42x41x82x81x162x161x322x321x642x64Operating Wavelengths(nm) 1260~1650Insertion Loss(dB)Max P/S4.04.07.37.610.511.013.514.416.517.520.521.0Loss Uniformity(dB)Max0.40.60.60.80.81.21.21.51.52.02.02.2PDL(dB)Max 0.2 0.2 0.2 0.2 0.2 0.30.25 0.3 0.30.4 0.350.4 Return Loss(dB)MinUPC: 50 APC: 55Directivity(dB)Min55Input FiberBend Insenstive SM Fiber(ITU G657A)Output FiberBend Insenstive SM Fiber(ITU G657A)Max. Optic Power(mw)300Humidity Range(rh)5% ~ 85%Opreating Temperature(° C)-40 ~ 85Storage Temperature(° C)-40 ~ 85Packaing OptionBare Device, Mini Tube, ABS Module, LGX BOX, 19' 1U 2U Rack-MountMini Tube(Metal) Dimension(mm) (LxWxH)50x4x450x7x450x7x460x12x480x20x6100x40x6ABS Module Dimension(mm) (LxWxH)100x80x10100x80x10100x80x10120x80x18120x80x18140x115x18BOX Dimension(mm) (LxWxH) LGX BOX, 19' 1U 2U Rack-Mount/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
