Light Guide Glass Fiber Bundle for Endoscope

3V TECHNOLOGY provides various types of bundled glass fiber products to realize light conduction and light shaping, light homogenizing, light collecting, light beam splitting, etc., make your optical system more efficient,more personalized with our customization support. It can also be assembled with collimating lens and coupling lens to collimate, converge and,beam expansion, etc., to optimize the performance of the optical system.We support customized sheathing tube(spiral metal tube inside to protect the fiber)Typical application:Industrial field;Medical field,Scientific research1>Smoke detection2>Particle detection3>Endoscope4>Testing instrument5>Laser therapy6>Fluorescence excitation7>Quanlity controlling8>DNA analysis9>Spectrum analysis10>Colorimetric analysis11>Protein analysis12>Sensor  13>Remote lighting  14>Flame analysis15>Cold light source16>Laser transmission17>Transmission wavelength range(nm):380-120018>NA value:0.56 ± 0.0219>Single fiber's diameter:30um/50um20>Projective outside tube:PVC,Stainless steel braided hose or customize(HFFR)21>Fiber Bundle's diameter(mm):3/5/8/10 or customize22>Fiber Bundle's length(m):1.0/1.5/2.0/3.0/5.0 or customize23>Temperature resistance range:-40~120ºC,-40~250ºC;24>Assembled customized lens is supportable(like collimating lend,focusing lens)/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
