FTTH Mini Sc IP68 Fiber Optic Waterproof Connector

FTTH Mini Sc IP68 Fiber Optic Waterproof Connector   Product DescriptionSuperTap cable assemblies provide the most cost-effective method of deploying optical fiber in outside plant distribution networks at speeds significantly fast than traditional field installations. The assemblies guarantee an easy, one-step connection system with the combined push-pull insertion and nut-style mechanical latch. SuperTap cable assembly provides quick installation solutions and has good performance on mating with SuperTap adapter. Cable can be amored or non-amored. SuperTap connector utilizes optical fiber cables upon which network access points are pre-installed at customer-specified locations along the length of the cable.Features:The most cost-effective methodAt speeds significantly fastQuick installation solutionsGood performance on mating with SuperTap adapterAmored or non-amoredSpecification:StandardsComply to GR-3120,GR-3152.IEC 61753-1.IEC 61754-4Insertation Loss (Super Tap/LC&SC)*Max 0.5dB,Mean 0.15dB (8° angled)Insertation Loss(Super Tap/MPO)Max 0.6dB,Mean 0.35dB(8° angled)Return Loss (Super Tap/LC&SC)*Min 60dB (8° angled)Return Loss(Super Tap/MPO)Min 60dB(8° angled)Operation Temperature-40 to 85ºCStorage Temperature-40 to 85ºCCable Dimension5.00mm 7.0mm or 4.5*7.0mm flatDust Cap Max.Pulling Force100IdWater ResistanceIP68  Applications:LAN, WAN and Metro NetworksFTTH project & FTTX DeploymentsCATV SystemGPON, EPONFiber Optic Test EquipmentData-base Transmit Broadband Net  Compliance:Telcordia GR-1209-CORE-2001Telcordia GR-1221-CORE-1999YD-T2000.1-2009RoHS    Product ParametersProduct photo:  Company Profile Starting with the Copper age in 1992, FIBCONET has gone through nearly 18 years in the fiber optic communication area.Now FIBCONET has 3 manufacturing centers, Ningbo, Guizhou, and Northeast China, covering more than 10,000 sqm,owning 800 well-trained staff and engineers, reaching the production capacity of PLC Splitter in 300,000 pcs and fiber opticalconnectors in 10 million pcs per month. As the national high-tech enterprise, FIBCONET also strives for more efforts in innovation.50 patents and 15 invention patents have been attained.FIBCONET focus on the fiber optical components, such as PLC splitter,patch cord, adapter, connectors, etc. Especially for the PLC splitter, can work in an extremely cold environment, even in the -50centigrade degree, like in Russia, FIBCONET's PLC can still help transmit the optical signal very well, And if you hope to get the0.1 dB for insert loss on your connectors, which is hard for the regular production, FIBCONET also can reach you.FIBCONET supplies goods all over the world through trading companies and agents, like Corning in the USA, Vodafone in Europe,Furukawa in Japan., etc. ISO9001, Rohs, and TLC certificates have already been approved by the market and our customers.With the new corporate vision: To be the top supplier for the fiber optical components, "Keep connecting" is our Motto, not only meansthat we produce the connectors and connect the fiber optic equipment, but also connect with the new technology, connect with everyFIBCONET person connects with our customers worldwide.Q: The History of our factory? A: In 2000, FIBCONET entered the communications industry and began to make adapters. It accumulated funds to invest in jumper production in 2006, and increased the optical splitter workshop in 2009. FIBCONET won the national high-tech industry in 2013, and sold over 15 million US dollars in 2015, and began to explore foreign markets. Q: The location of our factory? A: Our factory is located in Ningbo, Zhejiang, and our new factory has also been put into production, located in the Northeast (Jilin Province). Q: Occupied area for our factory ?A: The construction area of our factory is about 23,000 square meters, including 8000 square meters in Fenghua Plant and 15,000 square meters in Northeast China. Q: Production capacity for the Patch cord? A: 5,000,000 pcs per month. Q:What's your best price for your passive fiber optic product?A: Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time. Q:Do you offer guarantee for the products? A: Yes, we offer 1-2 years warranty to our formal products. Q:What action will you take if there are some product problems?A: If there are defective ones in the batch of products, we will offer spare ones for. 111#FTTH outdoor/indoor IP67 IP68 fiber optic waterproof connector mini sc patch cord connector112#FTTH fiber optic ip68 mini waterproof connector with lc sc mtp/mpo adapter113#FTTH fiber optic ip68 mini waterproof connector with lc sc mtp/mpo adapter114#FTTH fiber optic ip68 mini waterproof connector with lc sc mtp/mpo adapter115#FTTH fiber optic ip68 mini waterproof connector with lc sc mtp/mpo adapter116#FTTH fiber optic ip68 mini waterproof connector with lc sc mtp/mpo adapter/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.sp
