Soi High Speed Optical Switch Array

Chip-based multi-channel optical switch array is a product based on SOI platform, which could realize high-speed dynamic switching of optical signal with a response time on the order of nano-second. This product achieved the integration of an array of optical switches on a single SOI chip, and electro-optically co-packaged with fiber array and circuit board. It is thermally biased and digitally driven and has tiny polarization-sensitivity and low insertion loss.FeaturesMulti-channelsChip basedHigh speed responseApplicationsOptical fiber sensorOptical fiber communicationsFiber network monitoring and protection  SpecificationsParameters UnitMin.Typ. Max.NotesWavelength range nm1530-1570 nm  or 1270nm-1330 nm Extinction ratio dB192022 Insertion lossdB1.61.82.0 Return lossdB4050  PDLdB 0.30.5 drive voltageV0.911.2@300nsdrive current mA679@300nsResponse Timens30 300 Thermal tuning power consumptionmW30 50 number of channels 8-16 or Can be customized Transmission optical powermW80 Operating temperature range°C-20 50 Operating humidity range%  +65 DimensionsmmChip:20(L)×2.5 (W)×0.5(H)Component:90(L)x50(W)x13(H)can be customized Chip dimension                                  Component dimensionOrdering information  ZGWavelengthNumber of channelsType 13=1310nm15=1550nm1=1CH4=4CH8=8CH16=CH XX=other1=Without temperature regulating thermistor2=With temperature regulating thermistorXX=other  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
