High-Performance 1550nm External Modulation Optical Transmitter

1550nm External Optical TransmitterFWT-1550EH-2x7dBmCNR≥52dB, SBS:13~19dBm adj1 The product overview1.1 The product overviewFWT-1550EH-2x7 Externally Modulated Optical Transmitter product is a new type of high-performance 1550nm external modulation optical transmitter. The transmitter is the 1U height and can be easily installed in a 19 "rack. FWT-1550EH-2x7 transmitter is the 1550nm dual-wavelength 9dBm optical output, the output signal spectral lines is narrow, more advantages in the long-distance transmission. The main devices adopt DFB low-noise, narrow linewidth, continuous-wave lasers with the thermoelectric cooling device made in JDSU CATV high linearity external modulator. Because of the international brand adoption of key components and our company system optimization control technology, SNMP network control technology, the machine's technical performance indicators fully measure up the standard of similar imported equipment, It can provide high-quality images, digital or compressed digital signal long-distance transmission for cable television and telephone communications.1.2 The features       1.2.1) High quality: original system optimization control technology and RF pre-distortion technology ensure that the system can acquire the maximum CTB, CSO, and SBS targets in the case of excellent performance CNR.       1.2.2) Flexibility: In ensuring the high-performance system CSO, the phase modulation technology of external modulator maximizes the optical power into the fiber in order to obtain long-distance transmission, and the field adjustable SBS threshold, 13,16,19, may apply a different network transmission.      1.2.3) Reliability: The 19 "1U standard rack, built-in high-performance plug-in dual power supply, can work in the backup at 85 ∽ 265Vac City Network Voltage, MS-level automatic switching; chassis cooling automatic temperature control.       1.2.4) Intuitive: The laser is the most expensive machine component, machine equipped with a microprocessor monitors the working state of the laser, the panel LCD window displays the operating parameters.       1.2.5) Network type: Select an All-piece status monitoring transponder guarantee to meet the national standard and be compatible with the SCTE HMS standard, it enables network management monitoring capabilities.      1.2.6) AGC / MGC, auto setup2 The product structure diagram2.1 The Electrical block diagram   2.2 The transmitter's front panel, back panel diagram3 The main technical indicatorsNo.ItemUnitsParameterNote1Laser type FITEL From: JapaneseSee specifications2Wavelengthnm1550±10Specified before ordering3Optical Modulation Externally ModulatedJDSU From America4Optical output powerdBm2x7 5SBS thresholddBm19 13~19 dBm adj6Optical Connector SC/APC 7Frequency rangeMHz45~862 (1000)MHz 8CNRdB≥ 52dB @ link loss = 7 dB ; ≥ 51 @ link loss = 8 dB 9FlatnessdB±0.75GY/T143-2000 6.2.410RF input leveldBuV75~85 11C/CTBdB≥65.0 12C/CSOdB≥65.0 13RF input impedanceΩ75 14RF Input Return LossdB>16(45~870)MHz 15Channel Loading-77 NTSC / 60 PAL   16VCC      V90~265Vac220V AC, 50/60Hz17Power       W≤50Single-supply operation18Working TemperatureºC0~50Automatic temperature control19Storage temperature ºC-20~85 20Working relative humidity%20%~85% 21Size″19″×11″×1.75″(W)x(D)x(H)22Network management interface RJ45Supporting the MIB table for SNMP monitoring software and Web browserNote:1) In the condition of stipulated link-loss, configuration 60 PAL-D analog television channel signals within 550MHz frequency, in the range of 550MHz ~  870 MHz frequency transmit digital modulation signals, digital modulation signal level ( in 8MHz bandwidth) is 10dB lower than the analog signal carrier level when the optical input power is 0dBm, you can measure the carrier combination triple beat ratio (C / CTB), carrier combination of second-order beat ratio (C / CSO) and the carrier to noise ratio 2)Fiber:50KM+EDFA.-----------------------------------FAQ--------------------------------------------- 1. What are your terms of payment?Usually, we can accept T/T, PayPal, and Western Union. You can select the terms of payment which is more convenient for you.2. What about the lead time?Usually, if there is a stock of goods, we will deliver the goods within 3~5 workdays after we receive the payment.3. How about the shipping?Usually, we will deliver the goods via International Express like FedEx, DHL, TNT, and UPS, and so on. Door to door delivery service will be provided.4. How can I place an order?(1) Agreement is achieved on the product price and product specifications.(2) We make a proforma invoice for your confirmation.(3) When you agree on the proforma invoice, you make the payment.(4) We deliver the goods after we receive your payment.5. Can you do OEM for us?Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.6. What are the advantages of your products?A. Good quality and competitive prices.B. Strict quality control duri
