Top Quality Factory Price GYXTW Armored Outdoor Fiber Cable

Top quality factory price GYXTW Armored outdoor fiber cableAdvantages:1. Good supply capacity(100KM-200KM each day)2. Fast delivery time3. Complied to ISO9001 quality system4. 100% testing before shipment5. 1-24cores for option6. All kinds structures(GYXTW,GYTS,GYTA,GYFTY,GYTC8S) for option7. indoor and outdoor for option8. armored and non-armored Cable for optionSpecification of the indoor cable:Cable type   3.0   2.0   1.8   1.6Cable dimension(mm)2.85±0.1/5.8±0.21.95±0.1/4.0±0.21.80±0.1/3.7±0.21.65±0.1/3.6±0.2Cable weight(kg/km)1487.87.6TBF diameter(µm)900±50600±50Mechanical Characteristics:Tensile strength(N) Long term100Short term200Crush resistance(N/100mm)Long term100Short term500Bending Radius(CM)Dynamic20×H(H:Cable axis)Static10×H(H:Cable axis)FiberFiber type(core/cladding dimension)9/125,   50/125,    62.5/125Transmission Characteristics: SM  9/125OM2  50/125OM1  62.5/125 1310/1550(nm)850/1300(nm)850/1300(nm)Attenuation(dB/km)≤0.4/0.3≤3.5/1.5≤3.5/1.5Minimum Bandwidth(MHZkm)------≥400/400≥160/500Environmental Characteristics:Storage Temperature-20ºC+60ºCWorking temperature-20ºC+60ºCIndoor/Outdoor cable inside 12fiber or 24 fiber mini distribution armored cable 12 fiber 24 fiber Out diameter 6.0MM6.0MM Jacket Color Black or customizedBlack or customizedWeight /KG40kg/km40kg/kmTemperaturerange-40ºC~+80ºC-40ºC~+80ºCTensileStrengthDuringinstallation800NDuringinstallation800NIn service600NIn service600N Compressive strength≥100KGf/100MM≥100KGf/100MMAttenuation 1310nm0.35dB/km850nm3.0dB/km1550nm0.25dB/km1300nm1.0dB/kmMini bend radius ≥30D≥30DJacket MaterialPVC, LSZH ,OFNP, OFNR,PVC, LSZH ,OFNP, OFNRMetal tube size3.8mm to 3.9mm for the out diameter, 2.8 to 2.9mm for the inside diameter. Fiber TypeSM9/125, G657A1, G657A2, OM1. OM2,OM3, OM4Fiber BrandYOFC, OFS, CORNING  Application1. widely used for FTTA/FTTH/FTTB installation2. Data cable in distribution networks  Key Features:1. Rodent-protected, steel armoured2.For vertical applications3.For direct connector assembly4.Halogen free and self-extinguishing5.Low fire load for high safety requirements6.Longitudinal and transversal watertight cable CompanyCompetitive Advantage DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries. Certificate of qualificationProduction line:  Production lineTrade terms: EXW,FOB, CFR,CIF,FCA and so on   Payment terms: T/T, L/C, Western Union, Paypal(for sample order) Sample policy:Samples will be offered to you free of charge for some items.Please take action by just clicking the "Send" now/* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
