Custom CNC Machined 170kv D65L161 Waterproof Brushless Motor 10kw

Quanly D65L161 Underwater Thruster Brushless DC Electric Motor 10KW ApplicationsApplications:Electric Propulsion for various watercrafts 1. Efoil / Waterbike 2. Jet Surf/Surboard 3. Underwater thruster 4. Small boat /SUP / Kayak 5. POD drive 6. Jetski / Speed Boat 7. Yacht Either work with propeller directly or as an integrated part in a airtight cabin of trolling motor/outboard motor / POD    Product DescriptionQuanly D65L161 Series BLDC motors feature slotted design with internal rotor diameter at 65mm, compact & ruggedized, excellent heat dissipation, and waterproof. Thanks to the reduced air gap, the flux density is higher and torque production is more effective and efficient. Suitable for electric marine propulsion industry when your application requires accurate control of speed, torque and position.Can be customized for - Sensor or sensorless- Winding Current- Shaft Options- Cable and Connector- Kv Ratings- Mounting Options- Encoder or NonDyno Tester Report  Product Parameters VariantsD65L161-150D65L161-125D65L161-95 D65L161-76Turn2.5T 3T4T5TLiPo/voltage Range5-22S (16-84V)6-24S(20-100.8V)8-32S (25-134.4V)10-40S (32-168V)Max RPM12,600 12,600 12,76812,768Kv Rating1501259576No-load current at 8.4V2.6A2.0A1.5A1.2AMaximum output power11.2KW11.0KW10.8KW10.6KWKt(N*M/A)0.066780.078810.097780.12189Peak current (A) 245220170140Max torque (N*M)15.815.615.415.2Continuous working current (A)80706050 Effeciency 91%91%92%92%Weight(kg)2.52.52.52.5Construction 18N/6PDimension D65*L160Extension shaft D10*30mmLead wires extension 8AWGx2mConnection plug 8.0mm plugService life (life) 10,000HCustomize per your request Drawing DimensionWiring Diagram     /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
