High Precision Centerless Grinding Machine Model Tat-250ahr

The product is a carriage moving surface grinder, which mainly uses the periphery of the grinding wheel to grind the plane of the workpiece and the end face of the grinding wheel to grind the vertical surface of the workpiece.1. The precision of machining parts is high and the quality is stable. The positioning precision and repeated positioning precision of surface grinder  are very high.2. High degree of automation.3. Dimension marking should conform to the characteristics of grinding machine.4.The positioning datum is reliable.  ItemSpecificationsTable size (length X width)500*250mmMaximum left and right movement540mmMaximum front and back movement280mmThe distance between spindle center and worktable460mmThe maximum bearing capacity of worktable420KgDriving mode of worktableBall screw + ServoT-groove of worktable14X1mm/nWorktable speed 5-23m/minLongitudinal Handwheel Movement0.02mm/grid        5mm/rLongitudinal Automatic Handwheel Movement0.1-8mmLongitudinal Movement Rapid Speed50HZ  790mm/minGrinding Wheel Dim250*20*31.25mmSpindle speed 2800/3600r/minSpindle Diameter432mmUp and down handwheel feed 0.001/grid  0.2MM/rSpindle motor 1.5KWVertical motor 80KWUp and down motor 40WLongitudinal motor2.2KWPacking size2200*3050*1900MMNet weight 1350kg  /* January 22, 2024 19:08:37 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
